228  Graph-Based Retrieval-Augmented Generation

228.1 Introduction and Motivation

Retrieval-augmented generation addresses a fundamental limitation of large language models: their knowledge is frozen at training time and encoded implicitly within billions of parameters. When a user poses a question requiring information beyond the training corpus or demanding precise factual recall, standard language models either confabulate plausible-sounding but incorrect responses or acknowledge uncertainty without providing useful guidance. Retrieval-augmented generation circumvents this limitation by augmenting the generation process with explicit retrieval from an external knowledge store, allowing the model to condition its output on retrieved evidence.

The canonical retrieval-augmented generation architecture employs dense vector retrieval over a corpus of text chunks. Documents are segmented into passages, each passage is embedded into a high-dimensional vector space using a learned encoder, and at query time, the system retrieves passages whose embeddings exhibit high similarity to the query embedding. These retrieved passages are concatenated with the query and provided as context to the language model, which then generates a response grounded in the retrieved evidence.

This architecture, while effective for many applications, exhibits systematic weaknesses when confronted with queries requiring multi-hop reasoning, synthesis across disparate sources, or understanding of complex relational structures. Consider a query such as “What are the main research contributions of scientists who collaborated with both Geoffrey Hinton and Yann LeCun?” Answering this query requires identifying collaborators of Hinton, identifying collaborators of LeCun, computing the intersection, and then aggregating research contributions across the resulting set. A flat retrieval system operating over text chunks struggles with such queries because the relevant information is distributed across many documents, no single passage contains the complete answer, and the retrieval model has no mechanism for expressing or enforcing the relational constraints implicit in the query.

Graph-based retrieval-augmented generation addresses these limitations by organizing knowledge into a graph structure that explicitly represents entities and their relationships. Rather than treating a corpus as an undifferentiated collection of text chunks, graph-based approaches extract structured knowledge, represent it as nodes and edges in a graph, and leverage graph algorithms and graph neural networks to perform retrieval that respects relational structure. The graph serves as both an index and a reasoning substrate, enabling the system to traverse multi-hop paths, aggregate information across related entities, and provide the language model with contextualized, structured evidence.

The formulation that gave this family its name is due to Edge et al. (2024), whose GraphRAG system is the reference point for most of what follows. Their framing turns on a distinction that flat retrieval cannot express. A local query names its own evidence: “what side effects were reported for drug X” is answered by finding the passages about drug X, and top-\(k\) vector retrieval is a good instrument for that. A global query names none of it: “what are the main themes in this corpus” has no answer in any particular passage, because the answer is a property of the collection as a whole. No value of \(k\) helps, since the relevant text is the entire corpus and the operation required is summarization rather than retrieval. GraphRAG answers global queries by building, at index time, a hierarchy of entity communities over an extracted knowledge graph and having a language model write a summary of each community; a query is then answered by mapping over community summaries at a chosen level of the hierarchy and reducing the partial answers into one. The rest of this chapter develops the machinery that construction requires, and returns to the global-versus-local distinction once the community-detection tools are in place.

This chapter develops the theory, algorithms, and implementation of graph-based retrieval-augmented generation systems. We begin with the mathematical foundations of graphs and graph neural networks, proceed through knowledge graph construction and entity-relation extraction, develop retrieval algorithms that operate over graph structures, examine mechanisms for integrating graph-derived context into language model generation, and conclude with production considerations including scalability, evaluation, and deployment architecture.

228.2 Mathematical Foundations

228.2.1 Graph Theory Preliminaries

A graph \(G = (V, E)\) consists of a vertex set \(V\) and an edge set \(E \subseteq V \times V\). In the context of knowledge representation, vertices typically correspond to entities such as people, organizations, concepts, or documents, while edges represent relationships between entities. We denote the number of vertices as \(n = |V|\) and the number of edges as \(m = |E|\).

For knowledge graphs, we typically work with directed labeled graphs where edges carry semantic types. Formally, a knowledge graph is a tuple \(G = (V, E, R, \phi)\) where \(R\) is a set of relation types and \(\phi: E \to R\) assigns a relation type to each edge. An edge \((u, v) \in E\) with \(\phi((u,v)) = r\) is often written as a triple \((u, r, v)\), representing the assertion that entity \(u\) stands in relation \(r\) to entity \(v\).

The adjacency matrix \(A \in \{0,1\}^{n \times n}\) encodes graph structure, with \(A_{ij} = 1\) if and only if \((i, j) \in E\). For weighted graphs, \(A_{ij}\) takes values in \(\mathbb{R}_{\geq 0}\). The degree matrix \(D\) is diagonal with \(D_{ii} = \sum_j A_{ij}\). The graph Laplacian \(L = D - A\) plays a central role in spectral graph theory, with eigenvalues encoding structural properties of the graph.

The normalized Laplacian \(\mathcal{L} = I - D^{-1/2} A D^{-1/2}\) has eigenvalues in \([0, 2]\) and provides a basis for defining spectral graph convolutions. The eigendecomposition \(\mathcal{L} = U \Lambda U^T\) expresses the Laplacian in terms of orthonormal eigenvectors \(U\) and diagonal eigenvalue matrix \(\Lambda\).

228.2.2 Graph Neural Networks

Graph neural networks learn representations of graph-structured data by iteratively aggregating information from local neighborhoods. The fundamental operation is message passing: each vertex updates its representation by aggregating messages from its neighbors and combining the result with its current state.

Let \(h_v^{(l)} \in \mathbb{R}^d\) denote the hidden representation of vertex \(v\) at layer \(l\). The general message passing framework is expressed as:

\[m_v^{(l+1)} = \text{AGGREGATE}\left(\left\{ h_u^{(l)} : u \in \mathcal{N}(v) \right\}\right)\]

\[h_v^{(l+1)} = \text{UPDATE}\left(h_v^{(l)}, m_v^{(l+1)}\right)\]

where \(\mathcal{N}(v)\) denotes the neighborhood of vertex \(v\), AGGREGATE is a permutation-invariant function, and UPDATE combines the aggregated message with the current representation.

The Graph Convolutional Network (GCN) instantiates this framework with mean aggregation and linear transformation. The layer-wise propagation rule is:

\[H^{(l+1)} = \sigma\left(\tilde{D}^{-1/2} \tilde{A} \tilde{D}^{-1/2} H^{(l)} W^{(l)}\right)\]

where \(\tilde{A} = A + I\) adds self-loops, \(\tilde{D}\) is the corresponding degree matrix, \(W^{(l)} \in \mathbb{R}^{d_l \times d_{l+1}}\) is a learnable weight matrix, and \(\sigma\) is a nonlinearity such as ReLU.

This propagation rule can be derived from a first-order approximation to spectral graph convolutions. The spectral convolution of signal \(x\) with filter \(g_\theta\) is defined as:

\[g_\theta \star x = U g_\theta(\Lambda) U^T x\]

where \(g_\theta(\Lambda)\) is the filter evaluated at the eigenvalues. Taking \(g_\theta(\Lambda) = \sum_{k=0}^{K} \theta_k T_k(\tilde{\Lambda})\) as a Chebyshev polynomial expansion with \(\tilde{\Lambda} = \frac{2}{\lambda_{\max}} \Lambda - I\), and truncating at \(K=1\) with \(\lambda_{\max} = 2\), yields the GCN propagation rule.

The Graph Attention Network (GAT) replaces uniform neighborhood aggregation with learned attention weights:

\[\alpha_{ij} = \frac{\exp\left(\text{LeakyReLU}\left(a^T [W h_i \| W h_j]\right)\right)}{\sum_{k \in \mathcal{N}(i)} \exp\left(\text{LeakyReLU}\left(a^T [W h_i \| W h_k]\right)\right)}\]

\[h_i^{(l+1)} = \sigma\left(\sum_{j \in \mathcal{N}(i)} \alpha_{ij} W h_j^{(l)}\right)\]

where \(\|\) denotes concatenation, \(W\) is a shared linear transformation, and \(a\) is a learned attention vector. Multi-head attention extends this by concatenating or averaging outputs from multiple attention heads with independent parameters.

GraphSAGE introduces sampling-based aggregation for scalability to large graphs:

\[h_v^{(l+1)} = \sigma\left(W^{(l)} \cdot \text{CONCAT}\left(h_v^{(l)}, \text{AGG}\left(\{h_u^{(l)} : u \in \mathcal{S}(v)\}\right)\right)\right)\]

where \(\mathcal{S}(v)\) is a fixed-size sample from \(\mathcal{N}(v)\). Common aggregators include mean, LSTM over a random permutation, and max pooling.

228.2.3 Relational Graph Neural Networks

Knowledge graphs contain multiple relation types, requiring architectures that can handle heterogeneous edge labels. The Relational Graph Convolutional Network (R-GCN) extends GCN with relation-specific transformations:

\[h_i^{(l+1)} = \sigma\left(W_0^{(l)} h_i^{(l)} + \sum_{r \in R} \sum_{j \in \mathcal{N}_r(i)} \frac{1}{c_{i,r}} W_r^{(l)} h_j^{(l)}\right)\]

where \(\mathcal{N}_r(i)\) is the set of neighbors connected to \(i\) by relation \(r\), \(W_r^{(l)}\) is a relation-specific weight matrix, and \(c_{i,r}\) is a normalization constant typically set to \(|\mathcal{N}_r(i)|\).

The number of parameters grows linearly with the number of relations, which can be prohibitive for knowledge graphs with thousands of relation types. Two regularization strategies address this challenge. Basis decomposition represents each \(W_r\) as a linear combination of basis matrices: \(W_r^{(l)} = \sum_{b=1}^{B} a_{rb}^{(l)} V_b^{(l)}\) where \(B \ll |R|\). Block-diagonal decomposition constrains each \(W_r\) to be block-diagonal, reducing parameters while maintaining expressiveness.

228.2.4 Knowledge Graph Embeddings

Knowledge graph embedding methods learn low-dimensional representations of entities and relations that capture the semantic structure of the graph. These embeddings serve as initializations for graph neural networks and enable efficient approximate retrieval.

TransE models relations as translations in embedding space. Given a triple \((h, r, t)\), TransE enforces \(\mathbf{h} + \mathbf{r} \approx \mathbf{t}\) where \(\mathbf{h}, \mathbf{r}, \mathbf{t} \in \mathbb{R}^d\) are embeddings. The scoring function is:

\[f(h, r, t) = -\|\mathbf{h} + \mathbf{r} - \mathbf{t}\|_{p}\]

where \(p \in \{1, 2\}\). Training minimizes a margin-based ranking loss:

\[\mathcal{L} = \sum_{(h,r,t) \in S} \sum_{(h',r,t') \in S'} \max(0, \gamma + f(h',r,t') - f(h,r,t))\]

where \(S\) is the set of positive triples, \(S'\) is a set of corrupted triples with either head or tail replaced, and \(\gamma\) is the margin.

TransE struggles with one-to-many, many-to-one, and many-to-many relations because it enforces identical tail embeddings for all entities sharing a head-relation pair. RotatE addresses this by modeling relations as rotations in complex space:

\[f(h, r, t) = -\|\mathbf{h} \circ \mathbf{r} - \mathbf{t}\|\]

where \(\mathbf{h}, \mathbf{t} \in \mathbb{C}^d\), \(\mathbf{r} \in \mathbb{C}^d\) with \(|\mathbf{r}_i| = 1\), and \(\circ\) denotes element-wise product. This formulation can model symmetric, antisymmetric, inverse, and compositional relation patterns.

DistMult uses a bilinear scoring function: \(f(h, r, t) = \mathbf{h}^T \text{diag}(\mathbf{r}) \mathbf{t}\). ComplEx extends DistMult to complex space, enabling asymmetric relation modeling: \(f(h, r, t) = \text{Re}(\mathbf{h}^T \text{diag}(\mathbf{r}) \bar{\mathbf{t}})\) where \(\bar{\mathbf{t}}\) is the complex conjugate.

228.3 Knowledge Graph Construction

228.3.1 Entity and Relation Extraction

Constructing a knowledge graph from unstructured text requires extracting entities and the relations between them. The pipeline typically proceeds in stages: named entity recognition identifies entity mentions, entity linking grounds mentions to canonical entities in a knowledge base, and relation extraction identifies semantic relationships between entity pairs.

Named entity recognition is a sequence labeling task. Given a token sequence \(x_1, \ldots, x_n\), the model predicts a label sequence \(y_1, \ldots, y_n\) where labels follow a tagging scheme such as BIO (Beginning, Inside, Outside). Modern NER systems use transformer encoders with a linear classification layer:

\[P(y_i | x) = \text{softmax}(W h_i + b)\]

where \(h_i\) is the contextualized representation of token \(x_i\) from the transformer.

Relation extraction determines whether a semantic relation holds between a pair of identified entities. Given a sentence containing entities \(e_1\) and \(e_2\), the task is to classify the relation into one of a predefined set \(R \cup \{\text{NONE}\}\). Transformer-based relation extraction encodes the sentence with special markers indicating entity spans:

\[\text{[CLS]} \ldots \text{[E1]} e_1 \text{[/E1]} \ldots \text{[E2]} e_2 \text{[/E2]} \ldots \text{[SEP]}\]

The concatenation of \([\text{E1}]\) and \([\text{E2}]\) representations is passed through a classification layer.

Joint entity and relation extraction avoids error propagation by modeling both tasks simultaneously. The span-based approach enumerates all token spans up to a maximum length, classifies each span as an entity type or non-entity, and classifies each ordered pair of entity spans as a relation type or non-relation.

228.3.2 Large Language Models for Knowledge Extraction

Large language models can perform knowledge extraction through carefully designed prompts. The extraction process formulates entity and relation identification as text generation conditioned on schema specifications.

from typing import Any
from dataclasses import dataclass, field
import json
import hashlib


@dataclass
class Entity:
    """Represents an extracted entity."""
    name: str
    entity_type: str
    description: str = ""
    source_text: str = ""
    confidence: float = 1.0

    def __hash__(self):
        return hash((self.name.lower(), self.entity_type.lower()))

    def __eq__(self, other):
        if not isinstance(other, Entity):
            return False
        return (self.name.lower() == other.name.lower() and
                self.entity_type.lower() == other.entity_type.lower())


@dataclass
class Relation:
    """Represents an extracted relation between entities."""
    head: Entity
    relation_type: str
    tail: Entity
    confidence: float = 1.0
    source_text: str = ""

    def __hash__(self):
        return hash((hash(self.head), self.relation_type.lower(), hash(self.tail)))

    def __eq__(self, other):
        if not isinstance(other, Relation):
            return False
        return (self.head == other.head and
                self.relation_type.lower() == other.relation_type.lower() and
                self.tail == other.tail)


@dataclass
class ExtractionSchema:
    """Defines the schema for knowledge extraction."""
    entity_types: list[str]
    relation_types: list[tuple[str, str, str]]  # (head_type, relation, tail_type)

    def to_prompt_description(self) -> str:
        entity_desc = "Entity Types:\n" + "\n".join(
            f"  - {et}" for et in self.entity_types
        )
        relation_desc = "Relation Types:\n" + "\n".join(
            f"  - {head} --[{rel}]--> {tail}"
            for head, rel, tail in self.relation_types
        )
        return f"{entity_desc}\n\n{relation_desc}"


class KnowledgeExtractor:
    """Extracts entities and relations from text using an LLM."""

    def __init__(self, llm_client: Any, schema: ExtractionSchema):
        self.llm = llm_client
        self.schema = schema
        self.extraction_prompt = self._build_extraction_prompt()

    def _build_extraction_prompt(self) -> str:
        return f"""You are a knowledge extraction system. Extract entities and
relations from the provided text according to the following schema.

{self.schema.to_prompt_description()}

For each piece of text, output a JSON object with the following structure:
{{
    "entities": [
        {{"name": "...", "type": "...", "description": "..."}}
    ],
    "relations": [
        {{"head": "...", "relation": "...", "tail": "..."}}
    ]
}}

Only extract entities and relations that match the schema. Be precise and
conservative - only extract information that is explicitly stated or strongly
implied by the text. Do not infer or speculate."""

    def extract(self, text: str) -> tuple[list[Entity], list[Relation]]:
        """Extract entities and relations from text."""
        response = self.llm.generate(
            system_prompt=self.extraction_prompt,
            user_prompt=f"Extract knowledge from the following text:\n\n{text}",
            response_format="json"
        )

        parsed = json.loads(response)

        entities = {}
        for e in parsed.get("entities", []):
            entity = Entity(
                name=e["name"],
                entity_type=e["type"],
                description=e.get("description", ""),
                source_text=text[:500]
            )
            entities[entity.name.lower()] = entity

        relations = []
        for r in parsed.get("relations", []):
            head_name = r["head"].lower()
            tail_name = r["tail"].lower()

            if head_name in entities and tail_name in entities:
                relation = Relation(
                    head=entities[head_name],
                    relation_type=r["relation"],
                    tail=entities[tail_name],
                    source_text=text[:500]
                )
                relations.append(relation)

        return list(entities.values()), relations

    def extract_batch(
        self,
        texts: list[str],
        deduplicate: bool = True
    ) -> tuple[list[Entity], list[Relation]]:
        """Extract from multiple texts with optional deduplication."""
        all_entities = []
        all_relations = []

        for text in texts:
            entities, relations = self.extract(text)
            all_entities.extend(entities)
            all_relations.extend(relations)

        if deduplicate:
            all_entities = list(set(all_entities))
            all_relations = list(set(all_relations))

        return all_entities, all_relations

228.3.3 Coreference Resolution and Entity Linking

Raw extractions often contain multiple surface forms referring to the same underlying entity. Coreference resolution groups mentions that refer to the same entity within a document, while entity linking grounds mentions to canonical entities in an external knowledge base.

from dataclasses import dataclass, field
import numpy as np
from collections import defaultdict


@dataclass
class EntityMention:
    """A mention of an entity in text."""
    text: str
    start_char: int
    end_char: int
    document_id: str
    entity_type: str | None = None
    embedding: np.ndarray | None = None


@dataclass
class CanonicalEntity:
    """A canonical entity in the knowledge base."""
    entity_id: str
    name: str
    aliases: list[str] = field(default_factory=list)
    entity_type: str = ""
    description: str = ""
    embedding: np.ndarray | None = None


class EntityLinker:
    """Links entity mentions to canonical entities."""

    def __init__(
        self,
        embedding_model: Any,
        similarity_threshold: float = 0.85
    ):
        self.embedding_model = embedding_model
        self.similarity_threshold = similarity_threshold
        self.entity_index: dict[str, CanonicalEntity] = {}
        self.embedding_matrix: np.ndarray | None = None
        self.entity_ids: list[str] = []

    def build_index(self, entities: list[CanonicalEntity]):
        """Build search index from canonical entities."""
        self.entity_index = {e.entity_id: e for e in entities}
        self.entity_ids = list(self.entity_index.keys())

        # Compute embeddings for all entities
        texts = []
        for eid in self.entity_ids:
            entity = self.entity_index[eid]
            text = f"{entity.name}. {entity.description}"
            texts.append(text)

        embeddings = self.embedding_model.encode(texts)
        self.embedding_matrix = np.array(embeddings)

        # Normalize for cosine similarity
        norms = np.linalg.norm(self.embedding_matrix, axis=1, keepdims=True)
        self.embedding_matrix = self.embedding_matrix / (norms + 1e-10)

    def link(self, mention: EntityMention) -> tuple[str | None, float]:
        """Link a mention to a canonical entity."""
        if self.embedding_matrix is None:
            raise ValueError("Index not built. Call build_index first.")

        # Compute mention embedding
        mention_emb = self.embedding_model.encode([mention.text])[0]
        mention_emb = mention_emb / (np.linalg.norm(mention_emb) + 1e-10)

        # Compute similarities
        similarities = self.embedding_matrix @ mention_emb
        best_idx = np.argmax(similarities)
        best_score = similarities[best_idx]

        if best_score >= self.similarity_threshold:
            return self.entity_ids[best_idx], float(best_score)
        return None, float(best_score)

    def link_batch(
        self,
        mentions: list[EntityMention]
    ) -> list[tuple[str | None, float]]:
        """Link multiple mentions efficiently."""
        if not mentions:
            return []

        texts = [m.text for m in mentions]
        mention_embs = self.embedding_model.encode(texts)
        mention_embs = np.array(mention_embs)
        norms = np.linalg.norm(mention_embs, axis=1, keepdims=True)
        mention_embs = mention_embs / (norms + 1e-10)

        similarities = mention_embs @ self.embedding_matrix.T
        best_indices = np.argmax(similarities, axis=1)
        best_scores = similarities[np.arange(len(mentions)), best_indices]

        results = []
        for idx, score in zip(best_indices, best_scores):
            if score >= self.similarity_threshold:
                results.append((self.entity_ids[idx], float(score)))
            else:
                results.append((None, float(score)))

        return results


class CoreferenceResolver:
    """Resolves coreferences within documents."""

    def __init__(self, embedding_model: Any, threshold: float = 0.8):
        self.embedding_model = embedding_model
        self.threshold = threshold

    def resolve(
        self,
        mentions: list[EntityMention]
    ) -> list[list[EntityMention]]:
        """Cluster mentions that refer to the same entity."""
        if not mentions:
            return []

        # Compute embeddings
        texts = [m.text for m in mentions]
        embeddings = np.array(self.embedding_model.encode(texts))
        norms = np.linalg.norm(embeddings, axis=1, keepdims=True)
        embeddings = embeddings / (norms + 1e-10)

        # Compute pairwise similarities
        similarity_matrix = embeddings @ embeddings.T

        # Agglomerative clustering with threshold
        n = len(mentions)
        cluster_assignments = list(range(n))

        for i in range(n):
            for j in range(i + 1, n):
                if similarity_matrix[i, j] >= self.threshold:
                    # Merge clusters
                    old_cluster = cluster_assignments[j]
                    new_cluster = cluster_assignments[i]
                    for k in range(n):
                        if cluster_assignments[k] == old_cluster:
                            cluster_assignments[k] = new_cluster

        # Group by cluster
        clusters = defaultdict(list)
        for idx, cluster_id in enumerate(cluster_assignments):
            clusters[cluster_id].append(mentions[idx])

        return list(clusters.values())

228.3.4 Graph Construction Pipeline

The complete pipeline integrates extraction, coreference resolution, and entity linking to construct a knowledge graph from a document corpus.

from dataclasses import dataclass, field
from typing import Any
import hashlib
from collections import defaultdict


@dataclass
class KnowledgeGraph:
    """A knowledge graph with entities and relations."""
    entities: dict[str, Entity] = field(default_factory=dict)
    relations: list[Relation] = field(default_factory=list)
    entity_to_documents: dict[str, set[str]] = field(
        default_factory=lambda: defaultdict(set)
    )

    def add_entity(self, entity: Entity, document_id: str | None = None):
        """Add an entity to the graph."""
        entity_id = self._entity_id(entity)
        if entity_id not in self.entities:
            self.entities[entity_id] = entity
        if document_id:
            self.entity_to_documents[entity_id].add(document_id)
        return entity_id

    def add_relation(self, relation: Relation):
        """Add a relation to the graph."""
        if relation not in self.relations:
            self.relations.append(relation)

    def _entity_id(self, entity: Entity) -> str:
        """Generate stable ID for entity."""
        key = f"{entity.name.lower()}:{entity.entity_type.lower()}"
        return hashlib.sha256(key.encode()).hexdigest()[:16]

    def get_neighbors(
        self,
        entity_id: str,
        relation_type: str | None = None
    ) -> list[tuple[str, str, str]]:
        """Get neighboring entities via relations."""
        neighbors = []
        entity = self.entities.get(entity_id)
        if not entity:
            return neighbors

        for rel in self.relations:
            if rel.head == entity:
                if relation_type is None or rel.relation_type == relation_type:
                    tail_id = self._entity_id(rel.tail)
                    neighbors.append((tail_id, rel.relation_type, "outgoing"))
            elif rel.tail == entity:
                if relation_type is None or rel.relation_type == relation_type:
                    head_id = self._entity_id(rel.head)
                    neighbors.append((head_id, rel.relation_type, "incoming"))

        return neighbors

    def to_triples(self) -> list[tuple[str, str, str]]:
        """Convert to list of (head_id, relation, tail_id) triples."""
        triples = []
        for rel in self.relations:
            head_id = self._entity_id(rel.head)
            tail_id = self._entity_id(rel.tail)
            triples.append((head_id, rel.relation_type, tail_id))
        return triples

    def subgraph(
        self,
        entity_ids: set[str],
        max_hops: int = 1
    ) -> "KnowledgeGraph":
        """Extract subgraph around specified entities."""
        # Expand to include neighbors up to max_hops
        current_ids = entity_ids.copy()
        for _ in range(max_hops):
            new_ids = set()
            for eid in current_ids:
                for neighbor_id, _, _ in self.get_neighbors(eid):
                    new_ids.add(neighbor_id)
            current_ids = current_ids.union(new_ids)

        # Build subgraph
        subgraph = KnowledgeGraph()
        for eid in current_ids:
            if eid in self.entities:
                subgraph.entities[eid] = self.entities[eid]
                subgraph.entity_to_documents[eid] = self.entity_to_documents[eid]

        for rel in self.relations:
            head_id = self._entity_id(rel.head)
            tail_id = self._entity_id(rel.tail)
            if head_id in current_ids and tail_id in current_ids:
                subgraph.relations.append(rel)

        return subgraph


class GraphConstructionPipeline:
    """End-to-end pipeline for knowledge graph construction."""

    def __init__(
        self,
        extractor: KnowledgeExtractor,
        linker: EntityLinker | None = None,
        coreference_resolver: CoreferenceResolver | None = None
    ):
        self.extractor = extractor
        self.linker = linker
        self.coreference_resolver = coreference_resolver

    def process_documents(
        self,
        documents: list[dict[str, str]]
    ) -> KnowledgeGraph:
        """
        Process documents to build knowledge graph.

        Args:
            documents: List of {"id": ..., "text": ...} dictionaries

        Returns:
            Constructed knowledge graph
        """
        graph = KnowledgeGraph()
        all_mentions = []
        mention_to_doc = {}

        # Extract from each document
        for doc in documents:
            doc_id = doc["id"]
            text = doc["text"]

            entities, relations = self.extractor.extract(text)

            for entity in entities:
                entity_id = graph.add_entity(entity, doc_id)
                mention = EntityMention(
                    text=entity.name,
                    start_char=0,
                    end_char=len(entity.name),
                    document_id=doc_id,
                    entity_type=entity.entity_type
                )
                all_mentions.append(mention)
                mention_to_doc[id(mention)] = (entity, doc_id)

            for relation in relations:
                graph.add_relation(relation)

        # Apply coreference resolution if available
        if self.coreference_resolver:
            clusters = self.coreference_resolver.resolve(all_mentions)
            # Merge entities within clusters
            for cluster in clusters:
                if len(cluster) > 1:
                    self._merge_cluster(graph, cluster, mention_to_doc)

        return graph

    def _merge_cluster(
        self,
        graph: KnowledgeGraph,
        cluster: list[EntityMention],
        mention_to_doc: dict
    ):
        """Merge entities in a coreference cluster."""
        # Use most frequent mention as canonical
        mention_counts = defaultdict(int)
        for mention in cluster:
            mention_counts[mention.text.lower()] += 1

        canonical_text = max(mention_counts, key=mention_counts.get)

        # Find the canonical entity
        canonical_entity = None
        for mention in cluster:
            if mention.text.lower() == canonical_text:
                entity, _ = mention_to_doc.get(id(mention), (None, None))
                if entity:
                    canonical_entity = entity
                    break

        if not canonical_entity:
            return

        # Update relations to point to canonical entity
        canonical_id = graph._entity_id(canonical_entity)
        for mention in cluster:
            entity, _ = mention_to_doc.get(id(mention), (None, None))
            if entity and entity != canonical_entity:
                old_id = graph._entity_id(entity)
                # Remove old entity
                if old_id in graph.entities:
                    del graph.entities[old_id]
                # Update document mappings
                if old_id in graph.entity_to_documents:
                    graph.entity_to_documents[canonical_id].update(
                        graph.entity_to_documents[old_id]
                    )
                    del graph.entity_to_documents[old_id]

228.4 Graph-Based Retrieval

228.4.1 Embedding-Based Entity Retrieval

The first stage of graph-based retrieval identifies entities relevant to the query. Dense embedding methods project both query and entities into a shared vector space, enabling efficient similarity search.

import numpy as np
from typing import Any
from dataclasses import dataclass
import heapq


@dataclass
class RetrievedEntity:
    """An entity retrieved for a query."""
    entity_id: str
    entity: Entity
    score: float
    retrieval_method: str


class EntityRetriever:
    """Retrieves entities relevant to a query."""

    def __init__(
        self,
        embedding_model: Any,
        graph: KnowledgeGraph
    ):
        self.embedding_model = embedding_model
        self.graph = graph
        self.entity_embeddings: np.ndarray | None = None
        self.entity_id_list: list[str] = []

    def build_index(self):
        """Build embedding index for all entities."""
        self.entity_id_list = list(self.graph.entities.keys())

        texts = []
        for eid in self.entity_id_list:
            entity = self.graph.entities[eid]
            text = f"{entity.name}. Type: {entity.entity_type}. {entity.description}"
            texts.append(text)

        embeddings = self.embedding_model.encode(texts)
        self.entity_embeddings = np.array(embeddings)

        # Normalize
        norms = np.linalg.norm(self.entity_embeddings, axis=1, keepdims=True)
        self.entity_embeddings = self.entity_embeddings / (norms + 1e-10)

    def retrieve(
        self,
        query: str,
        top_k: int = 10
    ) -> list[RetrievedEntity]:
        """Retrieve top-k entities for query."""
        if self.entity_embeddings is None:
            raise ValueError("Index not built")

        query_emb = self.embedding_model.encode([query])[0]
        query_emb = query_emb / (np.linalg.norm(query_emb) + 1e-10)

        scores = self.entity_embeddings @ query_emb
        top_indices = np.argsort(scores)[-top_k:][::-1]

        results = []
        for idx in top_indices:
            entity_id = self.entity_id_list[idx]
            results.append(RetrievedEntity(
                entity_id=entity_id,
                entity=self.graph.entities[entity_id],
                score=float(scores[idx]),
                retrieval_method="embedding"
            ))

        return results


class HybridEntityRetriever:
    """Combines embedding and keyword-based retrieval."""

    def __init__(
        self,
        embedding_model: Any,
        graph: KnowledgeGraph,
        bm25_weight: float = 0.3
    ):
        self.embedding_retriever = EntityRetriever(embedding_model, graph)
        self.graph = graph
        self.bm25_weight = bm25_weight
        self.bm25_index = None

    def build_index(self):
        """Build both embedding and BM25 indices."""
        self.embedding_retriever.build_index()
        self._build_bm25_index()

    def _build_bm25_index(self):
        """Build BM25 index for keyword matching."""
        # Simple TF-IDF based index
        from collections import Counter
        import math

        self.doc_freqs = Counter()
        self.term_freqs = {}
        self.doc_lengths = {}

        for eid in self.graph.entities:
            entity = self.graph.entities[eid]
            text = f"{entity.name} {entity.entity_type} {entity.description}"
            tokens = text.lower().split()

            self.term_freqs[eid] = Counter(tokens)
            self.doc_lengths[eid] = len(tokens)

            for token in set(tokens):
                self.doc_freqs[token] += 1

        self.avg_doc_length = np.mean(list(self.doc_lengths.values()))
        self.num_docs = len(self.graph.entities)

    def _bm25_score(
        self,
        query_tokens: list[str],
        entity_id: str,
        k1: float = 1.5,
        b: float = 0.75
    ) -> float:
        """Compute BM25 score for entity."""
        import math

        score = 0.0
        tf = self.term_freqs.get(entity_id, Counter())
        doc_len = self.doc_lengths.get(entity_id, 0)

        for token in query_tokens:
            if token not in tf:
                continue

            freq = tf[token]
            df = self.doc_freqs.get(token, 0)

            idf = math.log((self.num_docs - df + 0.5) / (df + 0.5) + 1)
            tf_component = (freq * (k1 + 1)) / (
                freq + k1 * (1 - b + b * doc_len / self.avg_doc_length)
            )

            score += idf * tf_component

        return score

    def retrieve(
        self,
        query: str,
        top_k: int = 10
    ) -> list[RetrievedEntity]:
        """Retrieve using hybrid scoring."""
        # Get embedding scores
        embedding_results = self.embedding_retriever.retrieve(query, top_k * 2)
        embedding_scores = {r.entity_id: r.score for r in embedding_results}

        # Get BM25 scores
        query_tokens = query.lower().split()
        bm25_scores = {}
        for eid in self.graph.entities:
            bm25_scores[eid] = self._bm25_score(query_tokens, eid)

        # Normalize scores
        max_emb = max(embedding_scores.values()) if embedding_scores else 1.0
        max_bm25 = max(bm25_scores.values()) if bm25_scores else 1.0

        # Combine scores
        combined_scores = {}
        all_ids = set(embedding_scores.keys()) | set(bm25_scores.keys())

        for eid in all_ids:
            emb_score = embedding_scores.get(eid, 0) / max_emb
            bm25_score = bm25_scores.get(eid, 0) / (max_bm25 + 1e-10)

            combined_scores[eid] = (
                (1 - self.bm25_weight) * emb_score +
                self.bm25_weight * bm25_score
            )

        # Get top-k
        top_ids = heapq.nlargest(top_k, combined_scores, key=combined_scores.get)

        results = []
        for eid in top_ids:
            results.append(RetrievedEntity(
                entity_id=eid,
                entity=self.graph.entities[eid],
                score=combined_scores[eid],
                retrieval_method="hybrid"
            ))

        return results

228.4.2 Multi-Hop Graph Traversal

After identifying seed entities, graph traversal expands the context by following edges to discover related entities and paths. The traversal strategy must balance coverage with relevance, avoiding explosion of the subgraph while capturing necessary context.

from dataclasses import dataclass, field
from collections import deque
from typing import Callable
import numpy as np


@dataclass
class TraversalPath:
    """A path through the knowledge graph."""
    nodes: list[str]  # Entity IDs
    edges: list[str]  # Relation types
    score: float = 1.0

    def __len__(self):
        return len(self.nodes)

    @property
    def head(self) -> str:
        return self.nodes[0]

    @property
    def tail(self) -> str:
        return self.nodes[-1]


class GraphTraverser:
    """Traverses knowledge graph to expand context."""

    def __init__(
        self,
        graph: KnowledgeGraph,
        max_hops: int = 2,
        max_neighbors_per_hop: int = 10,
        relevance_scorer: Callable[[str, str], float] | None = None
    ):
        self.graph = graph
        self.max_hops = max_hops
        self.max_neighbors = max_neighbors_per_hop
        self.relevance_scorer = relevance_scorer or (lambda q, e: 0.0)

    def bfs_traverse(
        self,
        seed_entities: list[str],
        query: str
    ) -> tuple[set[str], list[TraversalPath]]:
        """
        Breadth-first traversal from seed entities.

        Returns:
            Tuple of (visited entity IDs, paths found)
        """
        visited = set(seed_entities)
        paths = [TraversalPath(nodes=[eid], edges=[]) for eid in seed_entities]
        all_paths = paths.copy()

        for hop in range(self.max_hops):
            new_paths = []

            for path in paths:
                current_id = path.tail
                neighbors = self.graph.get_neighbors(current_id)

                # Score neighbors by relevance
                scored_neighbors = []
                for neighbor_id, relation, direction in neighbors:
                    if neighbor_id not in visited:
                        entity = self.graph.entities.get(neighbor_id)
                        if entity:
                            score = self.relevance_scorer(query, entity.name)
                            scored_neighbors.append(
                                (neighbor_id, relation, direction, score)
                            )

                # Take top neighbors
                scored_neighbors.sort(key=lambda x: x[3], reverse=True)
                top_neighbors = scored_neighbors[:self.max_neighbors]

                for neighbor_id, relation, direction, score in top_neighbors:
                    visited.add(neighbor_id)
                    new_path = TraversalPath(
                        nodes=path.nodes + [neighbor_id],
                        edges=path.edges + [relation],
                        score=path.score * (0.5 + 0.5 * score)
                    )
                    new_paths.append(new_path)
                    all_paths.append(new_path)

            paths = new_paths

        return visited, all_paths

    def beam_search_traverse(
        self,
        seed_entities: list[str],
        query: str,
        beam_width: int = 5
    ) -> list[TraversalPath]:
        """
        Beam search traversal prioritizing relevant paths.
        """
        # Initialize beam with seed entities
        beam = [
            TraversalPath(nodes=[eid], edges=[], score=1.0)
            for eid in seed_entities
        ]

        for hop in range(self.max_hops):
            candidates = []

            for path in beam:
                current_id = path.tail
                neighbors = self.graph.get_neighbors(current_id)

                for neighbor_id, relation, direction in neighbors:
                    if neighbor_id not in path.nodes:  # Avoid cycles
                        entity = self.graph.entities.get(neighbor_id)
                        if entity:
                            score = self.relevance_scorer(query, entity.name)
                            new_path = TraversalPath(
                                nodes=path.nodes + [neighbor_id],
                                edges=path.edges + [relation],
                                score=path.score * (0.5 + 0.5 * score)
                            )
                            candidates.append(new_path)

            # Select top paths for beam
            candidates.sort(key=lambda p: p.score, reverse=True)
            beam = candidates[:beam_width]

            if not beam:
                break

        return beam

    def relation_constrained_traverse(
        self,
        seed_entities: list[str],
        relation_sequence: list[str]
    ) -> list[TraversalPath]:
        """
        Traverse following a specific sequence of relations.
        """
        current_paths = [
            TraversalPath(nodes=[eid], edges=[])
            for eid in seed_entities
        ]

        for required_relation in relation_sequence:
            new_paths = []

            for path in current_paths:
                current_id = path.tail
                neighbors = self.graph.get_neighbors(
                    current_id,
                    relation_type=required_relation
                )

                for neighbor_id, relation, direction in neighbors:
                    new_path = TraversalPath(
                        nodes=path.nodes + [neighbor_id],
                        edges=path.edges + [relation],
                        score=path.score
                    )
                    new_paths.append(new_path)

            current_paths = new_paths

            if not current_paths:
                break

        return current_paths

228.4.3 Graph Neural Network Retrieval

Graph neural networks can score subgraph relevance to a query by learning to propagate query information through the graph structure and computing relevance scores at the subgraph level.

import torch
import torch.nn as nn
import torch.nn.functional as F
from torch_geometric.nn import GATConv, global_mean_pool
from torch_geometric.data import Data, Batch
from typing import Any
import numpy as np


class QueryConditionedGNN(nn.Module):
    """GNN that conditions node representations on query."""

    def __init__(
        self,
        node_dim: int,
        query_dim: int,
        hidden_dim: int,
        num_layers: int = 3,
        num_heads: int = 4,
        dropout: float = 0.1
    ):
        super().__init__()

        self.query_proj = nn.Linear(query_dim, hidden_dim)
        self.node_proj = nn.Linear(node_dim, hidden_dim)

        # GAT layers
        self.gat_layers = nn.ModuleList()
        for i in range(num_layers):
            in_dim = hidden_dim if i == 0 else hidden_dim * num_heads
            self.gat_layers.append(
                GATConv(in_dim, hidden_dim, heads=num_heads, dropout=dropout)
            )

        # Query-node attention
        self.query_attention = nn.MultiheadAttention(
            embed_dim=hidden_dim * num_heads,
            num_heads=num_heads,
            dropout=dropout,
            batch_first=True
        )

        # Final scoring
        self.score_mlp = nn.Sequential(
            nn.Linear(hidden_dim * num_heads * 2, hidden_dim),
            nn.ReLU(),
            nn.Dropout(dropout),
            nn.Linear(hidden_dim, 1)
        )

        self.hidden_dim = hidden_dim
        self.num_heads = num_heads

    def forward(
        self,
        node_features: torch.Tensor,  # (num_nodes, node_dim)
        edge_index: torch.Tensor,  # (2, num_edges)
        query_embedding: torch.Tensor,  # (batch_size, query_dim)
        batch: torch.Tensor  # Node to graph assignment
    ) -> torch.Tensor:
        """
        Compute relevance scores for subgraphs.

        Returns:
            Tensor of shape (batch_size,) with relevance scores
        """
        # Project inputs
        h = self.node_proj(node_features)  # (num_nodes, hidden_dim)
        q = self.query_proj(query_embedding)  # (batch_size, hidden_dim)

        # Expand query to match nodes per graph
        batch_size = query_embedding.size(0)
        q_expanded = q[batch]  # (num_nodes, hidden_dim)

        # Condition node features on query
        h = h + q_expanded

        # GNN message passing
        for gat in self.gat_layers:
            h = F.elu(gat(h, edge_index))

        # Pool to graph level
        graph_emb = global_mean_pool(h, batch)  # (batch_size, hidden_dim * heads)

        # Query-graph attention
        q_final = q.unsqueeze(1).expand(-1, 1, self.hidden_dim)
        q_final = q_final.repeat(1, 1, self.num_heads)  # Match dimensions

        attn_output, _ = self.query_attention(
            q_final,
            graph_emb.unsqueeze(1),
            graph_emb.unsqueeze(1)
        )
        attn_output = attn_output.squeeze(1)

        # Compute score
        combined = torch.cat([graph_emb, attn_output], dim=-1)
        scores = self.score_mlp(combined).squeeze(-1)

        return scores


class GNNRetriever:
    """Retriever using GNN for subgraph scoring."""

    def __init__(
        self,
        gnn_model: QueryConditionedGNN,
        embedding_model: Any,
        graph: KnowledgeGraph,
        device: str = "cuda"
    ):
        self.gnn = gnn_model.to(device)
        self.embedding_model = embedding_model
        self.graph = graph
        self.device = device

        self._build_graph_tensors()

    def _build_graph_tensors(self):
        """Build tensor representations of the graph."""
        self.entity_id_to_idx = {
            eid: idx for idx, eid in enumerate(self.graph.entities.keys())
        }
        self.idx_to_entity_id = {
            idx: eid for eid, idx in self.entity_id_to_idx.items()
        }

        # Build edge index
        edges = []
        for rel in self.graph.relations:
            head_id = self.graph._entity_id(rel.head)
            tail_id = self.graph._entity_id(rel.tail)

            if head_id in self.entity_id_to_idx and tail_id in self.entity_id_to_idx:
                head_idx = self.entity_id_to_idx[head_id]
                tail_idx = self.entity_id_to_idx[tail_id]
                edges.append([head_idx, tail_idx])

        self.edge_index = torch.tensor(edges, dtype=torch.long).t().contiguous()

        # Build node features (entity embeddings)
        texts = []
        for eid in self.entity_id_to_idx:
            entity = self.graph.entities[eid]
            text = f"{entity.name}. {entity.description}"
            texts.append(text)

        embeddings = self.embedding_model.encode(texts)
        self.node_features = torch.tensor(embeddings, dtype=torch.float32)

    def retrieve_subgraph(
        self,
        query: str,
        seed_entities: list[str],
        max_hops: int = 2,
        top_k: int = 5
    ) -> list[tuple[set[str], float]]:
        """
        Retrieve and score subgraphs around seed entities.

        Returns:
            List of (entity_id_set, score) tuples
        """
        # Generate candidate subgraphs
        traverser = GraphTraverser(
            self.graph,
            max_hops=max_hops,
            max_neighbors_per_hop=10
        )

        subgraph_candidates = []
        for seed_id in seed_entities:
            visited, paths = traverser.bfs_traverse([seed_id], query)
            subgraph_candidates.append(visited)

        # Also try combinations of seeds
        if len(seed_entities) > 1:
            combined = set()
            for seed_id in seed_entities:
                visited, _ = traverser.bfs_traverse([seed_id], query)
                combined.update(visited)
            subgraph_candidates.append(combined)

        # Score subgraphs
        query_embedding = torch.tensor(
            self.embedding_model.encode([query]),
            dtype=torch.float32
        ).to(self.device)

        scored_subgraphs = []

        self.gnn.eval()
        with torch.no_grad():
            for entity_ids in subgraph_candidates:
                # Build subgraph data
                node_indices = [
                    self.entity_id_to_idx[eid]
                    for eid in entity_ids
                    if eid in self.entity_id_to_idx
                ]

                if not node_indices:
                    continue

                # Remap indices for subgraph
                idx_map = {old: new for new, old in enumerate(node_indices)}

                subgraph_features = self.node_features[node_indices].to(self.device)

                # Build subgraph edges
                subgraph_edges = []
                for i in range(self.edge_index.size(1)):
                    src, dst = self.edge_index[:, i].tolist()
                    if src in idx_map and dst in idx_map:
                        subgraph_edges.append([idx_map[src], idx_map[dst]])

                if subgraph_edges:
                    subgraph_edge_index = torch.tensor(
                        subgraph_edges, dtype=torch.long
                    ).t().contiguous().to(self.device)
                else:
                    subgraph_edge_index = torch.empty(
                        (2, 0), dtype=torch.long
                    ).to(self.device)

                batch = torch.zeros(
                    len(node_indices), dtype=torch.long
                ).to(self.device)

                score = self.gnn(
                    subgraph_features,
                    subgraph_edge_index,
                    query_embedding,
                    batch
                )

                scored_subgraphs.append((entity_ids, float(score.cpu())))

        # Return top-k
        scored_subgraphs.sort(key=lambda x: x[1], reverse=True)
        return scored_subgraphs[:top_k]

C:\Users\miken\github\ai_in_action\.venv\lib\site-packages\tqdm\auto.py:21: TqdmWarning:

IProgress not found. Please update jupyter and ipywidgets. See https://ipywidgets.readthedocs.io/en/stable/user_install.html

228.4.4 Community Detection for Document Clustering

For large knowledge graphs, community detection algorithms identify densely connected clusters of entities that can serve as coherent retrieval units. The Louvain algorithm optimizes modularity, a measure of the quality of a partition:

\[Q = \frac{1}{2m} \sum_{ij} \left[ A_{ij} - \frac{k_i k_j}{2m} \right] \delta(c_i, c_j)\]

where \(k_i\) is the degree of node \(i\), \(c_i\) is the community assignment of node \(i\), \(m\) is the total number of edges, and \(\delta\) is the Kronecker delta.

from collections import defaultdict
import random


class LouvainCommunityDetector:
    """Detects communities using the Louvain algorithm."""

    def __init__(self, graph: KnowledgeGraph, resolution: float = 1.0):
        self.graph = graph
        self.resolution = resolution
        self._build_adjacency()

    def _build_adjacency(self):
        """Build adjacency structure for modularity computation."""
        self.adjacency = defaultdict(lambda: defaultdict(float))
        self.degrees = defaultdict(float)
        self.total_weight = 0.0

        entity_ids = list(self.graph.entities.keys())

        for rel in self.graph.relations:
            head_id = self.graph._entity_id(rel.head)
            tail_id = self.graph._entity_id(rel.tail)

            if head_id in self.graph.entities and tail_id in self.graph.entities:
                self.adjacency[head_id][tail_id] += 1.0
                self.adjacency[tail_id][head_id] += 1.0
                self.degrees[head_id] += 1.0
                self.degrees[tail_id] += 1.0
                self.total_weight += 2.0

    def _modularity_gain(
        self,
        node: str,
        community: set[str],
        node_to_community: dict[str, int]
    ) -> float:
        """Compute modularity gain from moving node to community."""
        if self.total_weight == 0:
            return 0.0

        ki = self.degrees[node]
        ki_in = sum(
            self.adjacency[node].get(neighbor, 0)
            for neighbor in community
        )
        sigma_tot = sum(self.degrees[n] for n in community)

        gain = (
            ki_in / self.total_weight -
            self.resolution * ki * sigma_tot / (self.total_weight ** 2)
        )

        return gain

    def detect(self) -> dict[str, int]:
        """
        Detect communities using Louvain algorithm.

        Returns:
            Dictionary mapping entity IDs to community IDs
        """
        nodes = list(self.graph.entities.keys())

        # Initialize: each node in its own community
        node_to_community = {node: i for i, node in enumerate(nodes)}
        communities = {i: {node} for i, node in enumerate(nodes)}

        improved = True
        iteration = 0
        max_iterations = 100

        while improved and iteration < max_iterations:
            improved = False
            iteration += 1

            # Shuffle for randomization
            random.shuffle(nodes)

            for node in nodes:
                current_community_id = node_to_community[node]
                current_community = communities[current_community_id]

                # Remove node from current community
                current_community.discard(node)

                best_gain = 0.0
                best_community_id = current_community_id

                # Try neighboring communities
                neighbor_communities = set()
                for neighbor in self.adjacency[node]:
                    neighbor_communities.add(node_to_community[neighbor])

                for community_id in neighbor_communities:
                    community = communities[community_id]
                    gain = self._modularity_gain(
                        node, community, node_to_community
                    )

                    if gain > best_gain:
                        best_gain = gain
                        best_community_id = community_id

                # Move to best community
                if best_community_id != current_community_id:
                    improved = True

                communities[best_community_id].add(node)
                node_to_community[node] = best_community_id

                # Clean up empty community
                if not current_community and current_community_id != best_community_id:
                    del communities[current_community_id]

        # Renumber communities
        community_ids = sorted(communities.keys())
        id_mapping = {old: new for new, old in enumerate(community_ids)}

        return {
            node: id_mapping[comm_id]
            for node, comm_id in node_to_community.items()
        }


class CommunitySummarizer:
    """Generates summaries for entity communities."""

    def __init__(self, llm_client: Any, graph: KnowledgeGraph):
        self.llm = llm_client
        self.graph = graph

    def summarize_community(
        self,
        entity_ids: set[str],
        max_entities: int = 20
    ) -> str:
        """Generate a summary for a community of entities."""
        entities = [
            self.graph.entities[eid]
            for eid in list(entity_ids)[:max_entities]
            if eid in self.graph.entities
        ]

        if not entities:
            return ""

        entity_descriptions = "\n".join(
            f"- {e.name} ({e.entity_type}): {e.description}"
            for e in entities
        )

        # Get internal relations
        internal_relations = []
        for rel in self.graph.relations:
            head_id = self.graph._entity_id(rel.head)
            tail_id = self.graph._entity_id(rel.tail)
            if head_id in entity_ids and tail_id in entity_ids:
                internal_relations.append(
                    f"{rel.head.name} --[{rel.relation_type}]--> {rel.tail.name}"
                )

        relations_text = "\n".join(internal_relations[:30])

        prompt = f"""Summarize the following group of related entities into a
coherent paragraph that captures the main themes, relationships, and significance.

Entities:
{entity_descriptions}

Key Relationships:
{relations_text}

Write a concise summary (2-3 sentences) that would help someone understand
what this group of entities represents and how they relate to each other."""

        summary = self.llm.generate(user_prompt=prompt)
        return summary

    def summarize_all_communities(
        self,
        communities: dict[str, int]
    ) -> dict[int, str]:
        """Generate summaries for all communities."""
        # Group entities by community
        community_entities = defaultdict(set)
        for entity_id, community_id in communities.items():
            community_entities[community_id].add(entity_id)

        summaries = {}
        for community_id, entity_ids in community_entities.items():
            if len(entity_ids) >= 2:  # Only summarize non-trivial communities
                summaries[community_id] = self.summarize_community(entity_ids)

        return summaries

228.4.5 From Communities to Global Queries

The Louvain partition above is a clustering of a graph, and on its own it is only an indexing convenience. What Edge et al. (2024) add is an argument about which questions it makes answerable, and the argument is worth stating precisely because it is the strongest available justification for paying the cost of graph construction at all.

Recall the two query regimes. Write \(R_k(q)\) for the top-\(k\) passages a dense retriever returns for query \(q\), and let \(A^\star(q)\) be the set of source passages a correct and complete answer must draw on. A query is local when \(|A^\star(q)|\) is small and its members are individually similar to \(q\), so that \(A^\star(q) \subseteq R_k(q)\) for modest \(k\); a query is global when \(|A^\star(q)|\) grows with the corpus, or when its members bear no lexical or semantic resemblance to \(q\) at all. “What are the top themes in this dataset” is global under both readings: the evidence is every document, and no document is similar to the question. Increasing \(k\) cannot fix this, because the binding constraint is the context window, not the retriever. This is the failure mode that motivates the whole construction.

The GraphRAG answer is to pay for summarization once, at index time, rather than per query. Run entity and relation extraction over the corpus to obtain the graph \(G\) of the preceding sections. Partition it hierarchically, so that level \(\ell = 0\) is a fine partition into many small communities and each successive level merges them into fewer, larger ones; Edge et al. (2024) use the Leiden algorithm, a refinement of Louvain that repairs the badly connected communities Louvain can produce, but the modularity objective is the one derived above. For each community \(C\) at each level, have a language model write a self-contained summary \(\sigma(C)\) from the descriptions of the entities and relations it contains, working bottom-up so that a large community’s summary is composed from its children’s summaries rather than from raw text. The index is then the set \(\{\sigma(C)\}\) over all communities at all levels.

A global query is answered by a map-reduce over one level of that hierarchy. In the map step, each community summary at the chosen level \(\ell\) is placed in its own context window with the query, and the model produces a partial answer together with a self-reported helpfulness score in \([0, 100]\). In the reduce step, partial answers are sorted by score, filtered to drop the zeros, packed into a single context window, and synthesized into a final response. The structure matters more than the details: the map step is embarrassingly parallel and each of its calls sees a summary rather than raw passages, which is what lets the method reason over a corpus far larger than any context window. Choosing \(\ell\) trades breadth against cost. Low levels give many small, specific summaries and a large number of map calls; high levels give few broad summaries and a cheap query. Edge et al. (2024) report that intermediate levels of the hierarchy already match root-level summaries on answer quality at substantially lower token cost, and that across their two corpora both GraphRAG and a naive full-corpus summarization baseline beat vector RAG on comprehensiveness and diversity, with GraphRAG reaching that quality at a fraction of the per-query tokens.

The honest objection to all of this is the index-time bill. Summarizing every community at every level requires a language-model call per community, over a corpus that may not have been queried yet, and that up-front cost is what deters most teams from deploying graph RAG at all. Microsoft Research’s follow-on, LazyGraphRAG, attacks exactly this: it performs only the cheap, deterministic part of indexing, that is, graph construction and community detection with no language model involved, and defers every summarization call to query time, doing the work only for the communities a given query actually touches (Microsoft Research 2024). The reported effect is an indexing cost equal to that of plain vector RAG, roughly a thousandth of full GraphRAG’s, while retaining comparable global-query quality. The design principle generalizes past this system: in a retrieval architecture, any expensive transformation of the corpus that is not query-dependent should be examined for whether it can be made lazy, because the fraction of an index that a real query workload ever touches is usually small. The compact-model result of Komarov et al. (2026) later in this chapter is the same economy pursued along the other axis, shrinking the cost of each extraction call rather than avoiding the call.

228.5 Context Assembly and Generation

228.5.1 Hierarchical Context Construction

Retrieved graph elements must be assembled into a coherent context for the language model. Hierarchical construction organizes context from general to specific, starting with community summaries and proceeding to entity details and relationships.

from dataclasses import dataclass, field
from typing import Any


@dataclass
class GraphContext:
    """Structured context extracted from knowledge graph."""
    community_summaries: list[str] = field(default_factory=list)
    entity_descriptions: list[str] = field(default_factory=list)
    relationships: list[str] = field(default_factory=list)
    paths: list[str] = field(default_factory=list)
    source_documents: list[str] = field(default_factory=list)

    def to_text(self, max_tokens: int = 4000) -> str:
        """Convert to text format for LLM context."""
        sections = []

        if self.community_summaries:
            sections.append("## Overview\n" + "\n\n".join(self.community_summaries))

        if self.entity_descriptions:
            sections.append("## Key Entities\n" + "\n".join(self.entity_descriptions))

        if self.relationships:
            sections.append("## Relationships\n" + "\n".join(self.relationships))

        if self.paths:
            sections.append("## Reasoning Paths\n" + "\n".join(self.paths))

        if self.source_documents:
            sections.append("## Source Documents\n" + "\n---\n".join(self.source_documents))

        full_text = "\n\n".join(sections)

        # Simple truncation (in practice, use proper tokenization)
        if len(full_text) > max_tokens * 4:  # Rough char to token ratio
            full_text = full_text[:max_tokens * 4] + "\n[Context truncated...]"

        return full_text


class ContextAssembler:
    """Assembles context from graph retrieval results."""

    def __init__(
        self,
        graph: KnowledgeGraph,
        community_summaries: dict[int, str] | None = None,
        communities: dict[str, int] | None = None
    ):
        self.graph = graph
        self.community_summaries = community_summaries or {}
        self.communities = communities or {}

    def assemble(
        self,
        retrieved_entities: list[RetrievedEntity],
        paths: list[TraversalPath],
        include_communities: bool = True,
        max_entities: int = 20,
        max_relationships: int = 30,
        max_paths: int = 10
    ) -> GraphContext:
        """Assemble context from retrieval results."""
        context = GraphContext()

        # Collect entity IDs
        entity_ids = set()
        for re in retrieved_entities[:max_entities]:
            entity_ids.add(re.entity_id)
        for path in paths[:max_paths]:
            entity_ids.update(path.nodes)

        # Add community summaries
        if include_communities and self.community_summaries:
            relevant_communities = set()
            for eid in entity_ids:
                if eid in self.communities:
                    relevant_communities.add(self.communities[eid])

            for comm_id in relevant_communities:
                if comm_id in self.community_summaries:
                    context.community_summaries.append(
                        self.community_summaries[comm_id]
                    )

        # Add entity descriptions
        for re in retrieved_entities[:max_entities]:
            entity = re.entity
            desc = f"**{entity.name}** ({entity.entity_type})"
            if entity.description:
                desc += f": {entity.description}"
            context.entity_descriptions.append(desc)

        # Add relationships
        relationship_count = 0
        for rel in self.graph.relations:
            head_id = self.graph._entity_id(rel.head)
            tail_id = self.graph._entity_id(rel.tail)

            if head_id in entity_ids or tail_id in entity_ids:
                rel_text = f"{rel.head.name} --[{rel.relation_type}]--> {rel.tail.name}"
                context.relationships.append(rel_text)
                relationship_count += 1

                if relationship_count >= max_relationships:
                    break

        # Add paths as reasoning chains
        for path in paths[:max_paths]:
            if len(path.nodes) > 1:
                path_parts = []
                for i, node_id in enumerate(path.nodes):
                    entity = self.graph.entities.get(node_id)
                    if entity:
                        path_parts.append(entity.name)
                        if i < len(path.edges):
                            path_parts.append(f"--[{path.edges[i]}]-->")

                path_text = " ".join(path_parts)
                context.paths.append(path_text)

        # Add source document snippets
        for eid in list(entity_ids)[:10]:
            if eid in self.graph.entity_to_documents:
                docs = list(self.graph.entity_to_documents[eid])[:2]
                entity = self.graph.entities.get(eid)
                if entity and entity.source_text:
                    context.source_documents.append(
                        f"[{entity.name}] {entity.source_text[:500]}"
                    )

        return context


class GraphRAGGenerator:
    """Generates responses using graph-retrieved context."""

    def __init__(
        self,
        llm_client: Any,
        entity_retriever: HybridEntityRetriever,
        graph: KnowledgeGraph,
        traverser: GraphTraverser,
        context_assembler: ContextAssembler
    ):
        self.llm = llm_client
        self.entity_retriever = entity_retriever
        self.graph = graph
        self.traverser = traverser
        self.context_assembler = context_assembler

    def generate(
        self,
        query: str,
        top_k_entities: int = 10,
        max_hops: int = 2,
        include_reasoning: bool = True
    ) -> dict[str, Any]:
        """
        Generate response using graph-based retrieval.

        Returns:
            Dictionary with response, context, and metadata
        """
        # Retrieve relevant entities
        retrieved_entities = self.entity_retriever.retrieve(
            query,
            top_k=top_k_entities
        )

        # Traverse graph from retrieved entities
        seed_ids = [re.entity_id for re in retrieved_entities[:5]]
        visited, paths = self.traverser.bfs_traverse(seed_ids, query)

        # Assemble context
        context = self.context_assembler.assemble(
            retrieved_entities=retrieved_entities,
            paths=paths,
            max_entities=15,
            max_relationships=25,
            max_paths=8
        )

        # Build prompt
        context_text = context.to_text()

        system_prompt = """You are a helpful assistant that answers questions
using the provided knowledge graph context. Base your answers on the information
in the context. If the context doesn't contain enough information to fully
answer the question, acknowledge this and provide what you can based on the
available information.

When reasoning about relationships between entities, trace the connections
explicitly using the paths provided."""

        user_prompt = f"""Context from Knowledge Graph:

{context_text}

Question: {query}

Please provide a comprehensive answer based on the context above."""

        if include_reasoning:
            user_prompt += """

First, briefly explain your reasoning by tracing relevant entity relationships,
then provide your final answer."""

        response = self.llm.generate(
            system_prompt=system_prompt,
            user_prompt=user_prompt
        )

        return {
            "response": response,
            "context": context,
            "retrieved_entities": [
                {"name": re.entity.name, "score": re.score}
                for re in retrieved_entities
            ],
            "paths_traversed": len(paths),
            "entities_in_context": len(visited)
        }

228.5.2 Query Decomposition for Multi-Hop Questions

Complex queries often require decomposition into sub-queries that can be addressed independently and then synthesized. The decomposition strategy identifies the relational structure implicit in the query and generates targeted sub-queries.

from dataclasses import dataclass
from typing import Any
import json


@dataclass
class DecomposedQuery:
    """A query decomposed into sub-queries."""
    original_query: str
    sub_queries: list[str]
    dependencies: list[list[int]]  # Which sub-queries depend on which
    aggregation_strategy: str  # "union", "intersection", "chain", "synthesis"


class QueryDecomposer:
    """Decomposes complex queries into sub-queries."""

    def __init__(self, llm_client: Any):
        self.llm = llm_client

    def decompose(self, query: str) -> DecomposedQuery:
        """Decompose a complex query into sub-queries."""
        prompt = f"""Analyze the following question and determine if it requires
multi-step reasoning. If so, decompose it into simpler sub-questions that can
be answered independently and then combined.

Question: {query}

Respond with a JSON object:
{{
    "needs_decomposition": true/false,
    "sub_queries": ["sub-question 1", "sub-question 2", ...],
    "dependencies": [[indices of sub-queries that sub-query 0 depends on], ...],
    "aggregation_strategy": "union" | "intersection" | "chain" | "synthesis",
    "reasoning": "brief explanation of decomposition strategy"
}}

Aggregation strategies:
- "union": Combine results from all sub-queries
- "intersection": Find common elements across sub-query results
- "chain": Results from earlier sub-queries feed into later ones
- "synthesis": Combine insights to form a new conclusion

If the question is simple and doesn't need decomposition, return:
{{"needs_decomposition": false, "sub_queries": ["{query}"], "dependencies": [[]], "aggregation_strategy": "union"}}"""

        response = self.llm.generate(
            user_prompt=prompt,
            response_format="json"
        )

        parsed = json.loads(response)

        return DecomposedQuery(
            original_query=query,
            sub_queries=parsed["sub_queries"],
            dependencies=parsed["dependencies"],
            aggregation_strategy=parsed["aggregation_strategy"]
        )


class MultiHopGraphRAG:
    """Graph RAG with query decomposition and multi-hop reasoning."""

    def __init__(
        self,
        llm_client: Any,
        graph_rag: GraphRAGGenerator,
        decomposer: QueryDecomposer
    ):
        self.llm = llm_client
        self.graph_rag = graph_rag
        self.decomposer = decomposer

    def generate(self, query: str) -> dict[str, Any]:
        """Generate response with multi-hop reasoning."""
        # Decompose query
        decomposed = self.decomposer.decompose(query)

        if len(decomposed.sub_queries) == 1:
            # Simple query, no decomposition needed
            return self.graph_rag.generate(query)

        # Execute sub-queries in dependency order
        sub_results = [None] * len(decomposed.sub_queries)
        executed = set()

        while len(executed) < len(decomposed.sub_queries):
            for i, sub_query in enumerate(decomposed.sub_queries):
                if i in executed:
                    continue

                # Check if dependencies are satisfied
                deps = decomposed.dependencies[i]
                if all(d in executed for d in deps):
                    # Augment sub-query with prior results if chained
                    augmented_query = sub_query
                    if deps and decomposed.aggregation_strategy == "chain":
                        prior_context = "\n".join(
                            f"Prior finding: {sub_results[d]['response'][:500]}"
                            for d in deps
                            if sub_results[d]
                        )
                        augmented_query = f"{prior_context}\n\nCurrent question: {sub_query}"

                    sub_results[i] = self.graph_rag.generate(augmented_query)
                    executed.add(i)

        # Aggregate results
        final_response = self._aggregate_results(
            query=query,
            decomposed=decomposed,
            sub_results=sub_results
        )

        return {
            "response": final_response,
            "decomposed_query": decomposed,
            "sub_results": sub_results
        }

    def _aggregate_results(
        self,
        query: str,
        decomposed: DecomposedQuery,
        sub_results: list[dict]
    ) -> str:
        """Aggregate sub-query results into final response."""
        sub_findings = "\n\n".join(
            f"Sub-question {i+1}: {decomposed.sub_queries[i]}\n"
            f"Finding: {result['response']}"
            for i, result in enumerate(sub_results)
            if result
        )

        synthesis_prompt = f"""Original question: {query}

The question was broken down into sub-questions, and here are the findings:

{sub_findings}

Aggregation strategy: {decomposed.aggregation_strategy}

Based on these findings, provide a comprehensive answer to the original question.
Synthesize the information coherently, resolving any conflicts and highlighting
key connections between the sub-findings."""

        return self.llm.generate(user_prompt=synthesis_prompt)

228.6 Production Architecture

228.6.1 Indexing Pipeline

Production graph RAG systems require robust indexing pipelines that process documents, construct graphs, compute embeddings, and maintain indices incrementally.

from dataclasses import dataclass, field
from typing import Any, Iterator
import hashlib
from datetime import datetime
from abc import ABC, abstractmethod
import json


@dataclass
class Document:
    """A document to be indexed."""
    document_id: str
    text: str
    metadata: dict = field(default_factory=dict)
    timestamp: datetime = field(default_factory=datetime.now)


@dataclass
class IndexingResult:
    """Result of indexing a document."""
    document_id: str
    entities_extracted: int
    relations_extracted: int
    processing_time_ms: float
    success: bool
    error_message: str | None = None


class DocumentStore(ABC):
    """Abstract document storage."""

    @abstractmethod
    def store(self, document: Document) -> None:
        pass

    @abstractmethod
    def get(self, document_id: str) -> Document | None:
        pass

    @abstractmethod
    def list_ids(self) -> list[str]:
        pass


class GraphStore(ABC):
    """Abstract graph storage."""

    @abstractmethod
    def add_entity(self, entity: Entity, document_id: str) -> str:
        pass

    @abstractmethod
    def add_relation(self, relation: Relation) -> None:
        pass

    @abstractmethod
    def get_entity(self, entity_id: str) -> Entity | None:
        pass

    @abstractmethod
    def get_relations(
        self,
        entity_id: str,
        relation_type: str | None = None
    ) -> list[Relation]:
        pass


class VectorStore(ABC):
    """Abstract vector storage for embeddings."""

    @abstractmethod
    def add(
        self,
        ids: list[str],
        embeddings: list[list[float]],
        metadata: list[dict]
    ) -> None:
        pass

    @abstractmethod
    def search(
        self,
        query_embedding: list[float],
        top_k: int
    ) -> list[tuple[str, float]]:
        pass


class IndexingPipeline:
    """Production indexing pipeline for graph RAG."""

    def __init__(
        self,
        document_store: DocumentStore,
        graph_store: GraphStore,
        vector_store: VectorStore,
        extractor: KnowledgeExtractor,
        embedding_model: Any,
        batch_size: int = 10
    ):
        self.document_store = document_store
        self.graph_store = graph_store
        self.vector_store = vector_store
        self.extractor = extractor
        self.embedding_model = embedding_model
        self.batch_size = batch_size

    def index_document(self, document: Document) -> IndexingResult:
        """Index a single document."""
        import time
        start_time = time.time()

        try:
            # Store document
            self.document_store.store(document)

            # Extract entities and relations
            entities, relations = self.extractor.extract(document.text)

            # Store entities and compute embeddings
            entity_ids = []
            entity_texts = []

            for entity in entities:
                entity_id = self.graph_store.add_entity(entity, document.document_id)
                entity_ids.append(entity_id)
                entity_texts.append(
                    f"{entity.name}. {entity.entity_type}. {entity.description}"
                )

            # Store relations
            for relation in relations:
                self.graph_store.add_relation(relation)

            # Compute and store embeddings
            if entity_texts:
                embeddings = self.embedding_model.encode(entity_texts)
                metadata = [
                    {"document_id": document.document_id, "entity_name": e.name}
                    for e in entities
                ]
                self.vector_store.add(entity_ids, embeddings.tolist(), metadata)

            processing_time = (time.time() - start_time) * 1000

            return IndexingResult(
                document_id=document.document_id,
                entities_extracted=len(entities),
                relations_extracted=len(relations),
                processing_time_ms=processing_time,
                success=True
            )

        except Exception as e:
            processing_time = (time.time() - start_time) * 1000
            return IndexingResult(
                document_id=document.document_id,
                entities_extracted=0,
                relations_extracted=0,
                processing_time_ms=processing_time,
                success=False,
                error_message=str(e)
            )

    def index_batch(
        self,
        documents: list[Document]
    ) -> Iterator[IndexingResult]:
        """Index documents in batches."""
        for i in range(0, len(documents), self.batch_size):
            batch = documents[i:i + self.batch_size]
            for doc in batch:
                yield self.index_document(doc)

    def reindex_all(self) -> list[IndexingResult]:
        """Reindex all documents."""
        document_ids = self.document_store.list_ids()
        results = []

        for doc_id in document_ids:
            doc = self.document_store.get(doc_id)
            if doc:
                result = self.index_document(doc)
                results.append(result)

        return results

228.6.2 Caching and Performance Optimization

Production systems require caching at multiple levels to achieve acceptable latency. Query result caching, embedding caching, and subgraph caching each address different performance bottlenecks.

from dataclasses import dataclass
from typing import Any, Generic, TypeVar
from abc import ABC, abstractmethod
import hashlib
import time
from collections import OrderedDict
import threading


T = TypeVar('T')


class Cache(ABC, Generic[T]):
    """Abstract cache interface."""

    @abstractmethod
    def get(self, key: str) -> T | None:
        pass

    @abstractmethod
    def set(self, key: str, value: T, ttl_seconds: int | None = None) -> None:
        pass

    @abstractmethod
    def delete(self, key: str) -> None:
        pass


class LRUCache(Cache[T]):
    """Thread-safe LRU cache implementation."""

    def __init__(self, max_size: int = 1000):
        self.max_size = max_size
        self.cache: OrderedDict[str, tuple[T, float | None]] = OrderedDict()
        self.lock = threading.Lock()

    def get(self, key: str) -> T | None:
        with self.lock:
            if key not in self.cache:
                return None

            value, expiry = self.cache[key]

            # Check expiry
            if expiry is not None and time.time() > expiry:
                del self.cache[key]
                return None

            # Move to end (most recently used)
            self.cache.move_to_end(key)
            return value

    def set(self, key: str, value: T, ttl_seconds: int | None = None) -> None:
        with self.lock:
            expiry = None
            if ttl_seconds is not None:
                expiry = time.time() + ttl_seconds

            if key in self.cache:
                self.cache.move_to_end(key)
            self.cache[key] = (value, expiry)

            # Evict oldest if over capacity
            while len(self.cache) > self.max_size:
                self.cache.popitem(last=False)

    def delete(self, key: str) -> None:
        with self.lock:
            if key in self.cache:
                del self.cache[key]


@dataclass
class CachedQueryResult:
    """Cached result for a query."""
    response: str
    context: GraphContext
    retrieved_entities: list[dict]
    timestamp: float


class CachedGraphRAG:
    """Graph RAG with multi-level caching."""

    def __init__(
        self,
        graph_rag: GraphRAGGenerator,
        embedding_model: Any,
        query_cache: Cache[CachedQueryResult] | None = None,
        embedding_cache: Cache[list[float]] | None = None,
        cache_ttl_seconds: int = 3600
    ):
        self.graph_rag = graph_rag
        self.embedding_model = embedding_model
        self.query_cache = query_cache or LRUCache(max_size=1000)
        self.embedding_cache = embedding_cache or LRUCache(max_size=10000)
        self.cache_ttl = cache_ttl_seconds

    def _query_cache_key(self, query: str) -> str:
        """Generate cache key for query."""
        return hashlib.sha256(query.lower().strip().encode()).hexdigest()

    def _embedding_cache_key(self, text: str) -> str:
        """Generate cache key for embedding."""
        return hashlib.sha256(text.encode()).hexdigest()

    def get_embedding(self, text: str) -> list[float]:
        """Get embedding with caching."""
        cache_key = self._embedding_cache_key(text)

        cached = self.embedding_cache.get(cache_key)
        if cached is not None:
            return cached

        embedding = self.embedding_model.encode([text])[0].tolist()
        self.embedding_cache.set(cache_key, embedding, self.cache_ttl)

        return embedding

    def generate(
        self,
        query: str,
        use_cache: bool = True,
        **kwargs
    ) -> dict[str, Any]:
        """Generate with query result caching."""
        cache_key = self._query_cache_key(query)

        if use_cache:
            cached = self.query_cache.get(cache_key)
            if cached is not None:
                return {
                    "response": cached.response,
                    "context": cached.context,
                    "retrieved_entities": cached.retrieved_entities,
                    "cached": True,
                    "cache_age_seconds": time.time() - cached.timestamp
                }

        # Generate fresh result
        result = self.graph_rag.generate(query, **kwargs)

        # Cache result
        cached_result = CachedQueryResult(
            response=result["response"],
            context=result["context"],
            retrieved_entities=result["retrieved_entities"],
            timestamp=time.time()
        )
        self.query_cache.set(cache_key, cached_result, self.cache_ttl)

        result["cached"] = False
        return result

    def invalidate_query(self, query: str) -> None:
        """Invalidate cached result for query."""
        cache_key = self._query_cache_key(query)
        self.query_cache.delete(cache_key)

    def warm_cache(self, queries: list[str]) -> None:
        """Pre-warm cache with common queries."""
        for query in queries:
            self.generate(query, use_cache=False)

228.6.3 Evaluation Framework

Rigorous evaluation requires metrics that capture both retrieval quality and generation accuracy. For graph RAG, additional metrics assess the quality of graph traversal and context assembly.

from dataclasses import dataclass, field
from typing import Any
import numpy as np
from collections import defaultdict


@dataclass
class EvaluationExample:
    """A single evaluation example."""
    query: str
    ground_truth_answer: str
    ground_truth_entities: list[str]  # Entity names that should be retrieved
    ground_truth_paths: list[list[str]] | None = None  # Expected reasoning paths


@dataclass
class RetrievalMetrics:
    """Metrics for retrieval evaluation."""
    precision: float
    recall: float
    f1: float
    mrr: float  # Mean Reciprocal Rank
    ndcg: float  # Normalized Discounted Cumulative Gain


@dataclass
class GenerationMetrics:
    """Metrics for generation evaluation."""
    answer_relevance: float  # 0-1 score from LLM judge
    factual_consistency: float  # 0-1 score for consistency with context
    completeness: float  # 0-1 score for answer completeness


@dataclass
class GraphRAGMetrics:
    """Combined metrics for graph RAG evaluation."""
    retrieval: RetrievalMetrics
    generation: GenerationMetrics
    path_accuracy: float  # Fraction of expected paths found
    context_efficiency: float  # Relevant entities / total entities in context


class GraphRAGEvaluator:
    """Evaluates graph RAG system performance."""

    def __init__(self, llm_judge: Any):
        self.llm_judge = llm_judge

    def evaluate_retrieval(
        self,
        retrieved_entities: list[str],
        ground_truth_entities: list[str]
    ) -> RetrievalMetrics:
        """Evaluate retrieval quality."""
        retrieved_set = set(e.lower() for e in retrieved_entities)
        ground_truth_set = set(e.lower() for e in ground_truth_entities)

        if not retrieved_set:
            return RetrievalMetrics(0, 0, 0, 0, 0)

        # Precision and recall
        true_positives = len(retrieved_set & ground_truth_set)
        precision = true_positives / len(retrieved_set)
        recall = true_positives / len(ground_truth_set) if ground_truth_set else 0
        f1 = 2 * precision * recall / (precision + recall) if (precision + recall) > 0 else 0

        # MRR
        mrr = 0.0
        for i, entity in enumerate(retrieved_entities):
            if entity.lower() in ground_truth_set:
                mrr = 1.0 / (i + 1)
                break

        # NDCG
        relevance = [
            1.0 if e.lower() in ground_truth_set else 0.0
            for e in retrieved_entities
        ]
        dcg = sum(rel / np.log2(i + 2) for i, rel in enumerate(relevance))

        ideal_relevance = sorted(relevance, reverse=True)
        idcg = sum(rel / np.log2(i + 2) for i, rel in enumerate(ideal_relevance))
        ndcg = dcg / idcg if idcg > 0 else 0

        return RetrievalMetrics(
            precision=precision,
            recall=recall,
            f1=f1,
            mrr=mrr,
            ndcg=ndcg
        )

    def evaluate_generation(
        self,
        query: str,
        generated_answer: str,
        ground_truth_answer: str,
        context: str
    ) -> GenerationMetrics:
        """Evaluate generation quality using LLM judge."""
        # Answer relevance
        relevance_prompt = f"""Rate how well the generated answer addresses the question.

Question: {query}
Generated Answer: {generated_answer}
Reference Answer: {ground_truth_answer}

Rate from 0 to 1 where:
0 = Completely irrelevant or incorrect
0.5 = Partially relevant but missing key information
1 = Fully relevant and accurate

Output only a number between 0 and 1."""

        relevance_score = float(self.llm_judge.generate(user_prompt=relevance_prompt))

        # Factual consistency
        consistency_prompt = f"""Check if the generated answer is consistent with the provided context.
Does the answer make claims that contradict or go beyond the context?

Context: {context[:2000]}
Generated Answer: {generated_answer}

Rate factual consistency from 0 to 1 where:
0 = Major contradictions or unsupported claims
0.5 = Some minor inconsistencies
1 = Fully consistent with context

Output only a number between 0 and 1."""

        consistency_score = float(self.llm_judge.generate(user_prompt=consistency_prompt))

        # Completeness
        completeness_prompt = f"""Evaluate the completeness of the generated answer compared to the reference.

Question: {query}
Generated Answer: {generated_answer}
Reference Answer: {ground_truth_answer}

Rate completeness from 0 to 1 where:
0 = Missing most key information
0.5 = Covers some but not all important points
1 = Covers all key information from reference

Output only a number between 0 and 1."""

        completeness_score = float(self.llm_judge.generate(user_prompt=completeness_prompt))

        return GenerationMetrics(
            answer_relevance=relevance_score,
            factual_consistency=consistency_score,
completeness=completeness_score
        )

    def evaluate_example(
        self,
        example: EvaluationExample,
        result: dict[str, Any]
    ) -> GraphRAGMetrics:
        """Evaluate a single example."""
        # Retrieval metrics
        retrieved_names = [e["name"] for e in result.get("retrieved_entities", [])]
        retrieval_metrics = self.evaluate_retrieval(
            retrieved_names,
            example.ground_truth_entities
        )

        # Generation metrics
        context_text = result.get("context", GraphContext()).to_text()
        generation_metrics = self.evaluate_generation(
            query=example.query,
            generated_answer=result.get("response", ""),
            ground_truth_answer=example.ground_truth_answer,
            context=context_text
        )

        # Path accuracy (if ground truth paths provided)
        path_accuracy = 0.0
        if example.ground_truth_paths:
            # This would require more sophisticated path matching
            path_accuracy = 0.5  # Placeholder

        # Context efficiency
        retrieved_set = set(e.lower() for e in retrieved_names)
        ground_truth_set = set(e.lower() for e in example.ground_truth_entities)
        relevant_in_context = len(retrieved_set & ground_truth_set)
        total_in_context = len(retrieved_set)
        context_efficiency = relevant_in_context / total_in_context if total_in_context > 0 else 0

        return GraphRAGMetrics(
            retrieval=retrieval_metrics,
            generation=generation_metrics,
            path_accuracy=path_accuracy,
            context_efficiency=context_efficiency
        )

    def evaluate_dataset(
        self,
        examples: list[EvaluationExample],
        graph_rag: Any
    ) -> dict[str, float]:
        """Evaluate on a dataset and compute aggregate metrics."""
        all_metrics = []

        for example in examples:
            result = graph_rag.generate(example.query)
            metrics = self.evaluate_example(example, result)
            all_metrics.append(metrics)

        # Aggregate
        aggregated = {
            "retrieval_precision": np.mean([m.retrieval.precision for m in all_metrics]),
            "retrieval_recall": np.mean([m.retrieval.recall for m in all_metrics]),
            "retrieval_f1": np.mean([m.retrieval.f1 for m in all_metrics]),
            "retrieval_mrr": np.mean([m.retrieval.mrr for m in all_metrics]),
            "retrieval_ndcg": np.mean([m.retrieval.ndcg for m in all_metrics]),
            "generation_relevance": np.mean([m.generation.answer_relevance for m in all_metrics]),
            "generation_consistency": np.mean([m.generation.factual_consistency for m in all_metrics]),
            "generation_completeness": np.mean([m.generation.completeness for m in all_metrics]),
            "path_accuracy": np.mean([m.path_accuracy for m in all_metrics]),
            "context_efficiency": np.mean([m.context_efficiency for m in all_metrics])
        }

        return aggregated

228.7 Deployment Considerations

228.7.1 Service Architecture

Production graph RAG systems typically decompose into separate services for indexing, retrieval, and generation, enabling independent scaling and optimization.

from dataclasses import dataclass
from typing import Any
from abc import ABC, abstractmethod
import asyncio
from concurrent.futures import ThreadPoolExecutor


@dataclass
class ServiceConfig:
    """Configuration for graph RAG service."""
    max_concurrent_requests: int = 100
    request_timeout_seconds: float = 30.0
    indexing_batch_size: int = 10
    retrieval_top_k: int = 10
    max_context_tokens: int = 4000
    enable_caching: bool = True
    cache_ttl_seconds: int = 3600


class GraphRAGService:
    """Production service for graph RAG."""

    def __init__(
        self,
        config: ServiceConfig,
        indexing_pipeline: IndexingPipeline,
        graph_rag: CachedGraphRAG,
        multi_hop_rag: MultiHopGraphRAG
    ):
        self.config = config
        self.indexing_pipeline = indexing_pipeline
        self.graph_rag = graph_rag
        self.multi_hop_rag = multi_hop_rag
        self.executor = ThreadPoolExecutor(max_workers=config.max_concurrent_requests)
        self._semaphore = asyncio.Semaphore(config.max_concurrent_requests)

    async def query(
        self,
        query: str,
        use_multi_hop: bool = False,
        **kwargs
    ) -> dict[str, Any]:
        """Process a query asynchronously."""
        async with self._semaphore:
            loop = asyncio.get_event_loop()

            if use_multi_hop:
                result = await loop.run_in_executor(
                    self.executor,
                    lambda: self.multi_hop_rag.generate(query)
                )
            else:
                result = await loop.run_in_executor(
                    self.executor,
                    lambda: self.graph_rag.generate(query, **kwargs)
                )

            return result

    async def index_documents(
        self,
        documents: list[Document]
    ) -> list[IndexingResult]:
        """Index documents asynchronously."""
        loop = asyncio.get_event_loop()

        results = await loop.run_in_executor(
            self.executor,
            lambda: list(self.indexing_pipeline.index_batch(documents))
        )

        return results

    def health_check(self) -> dict[str, Any]:
        """Check service health."""
        return {
            "status": "healthy",
            "pending_requests": self.config.max_concurrent_requests - self._semaphore._value,
            "cache_enabled": self.config.enable_caching
        }

228.7.2 Observability and Monitoring

Production systems require comprehensive observability to diagnose issues and optimize performance. Key metrics include retrieval latency, generation latency, cache hit rates, and retrieval quality indicators.

from dataclasses import dataclass, field
from typing import Any, Callable
import time
from collections import defaultdict
import threading
from contextlib import contextmanager


@dataclass
class MetricPoint:
    """A single metric observation."""
    name: str
    value: float
    timestamp: float
    labels: dict[str, str] = field(default_factory=dict)


class MetricsCollector:
    """Collects and exposes metrics."""

    def __init__(self):
        self.counters: dict[str, float] = defaultdict(float)
        self.gauges: dict[str, float] = defaultdict(float)
        self.histograms: dict[str, list[float]] = defaultdict(list)
        self.lock = threading.Lock()

    def increment_counter(
        self,
        name: str,
        value: float = 1.0,
        labels: dict[str, str] | None = None
    ):
        """Increment a counter metric."""
        key = self._make_key(name, labels)
        with self.lock:
            self.counters[key] += value

    def set_gauge(
        self,
        name: str,
        value: float,
        labels: dict[str, str] | None = None
    ):
        """Set a gauge metric."""
        key = self._make_key(name, labels)
        with self.lock:
            self.gauges[key] = value

    def observe_histogram(
        self,
        name: str,
        value: float,
        labels: dict[str, str] | None = None
    ):
        """Add observation to histogram."""
        key = self._make_key(name, labels)
        with self.lock:
            self.histograms[key].append(value)
            # Keep only last 1000 observations
            if len(self.histograms[key]) > 1000:
                self.histograms[key] = self.histograms[key][-1000:]

    def _make_key(self, name: str, labels: dict[str, str] | None) -> str:
        """Create metric key from name and labels."""
        if not labels:
            return name
        label_str = ",".join(f"{k}={v}" for k, v in sorted(labels.items()))
        return f"{name}{{{label_str}}}"

    @contextmanager
    def timer(self, name: str, labels: dict[str, str] | None = None):
        """Context manager for timing operations."""
        start = time.time()
        try:
            yield
        finally:
            duration = time.time() - start
            self.observe_histogram(name, duration, labels)

    def get_metrics(self) -> dict[str, Any]:
        """Get all metrics."""
        with self.lock:
            histogram_stats = {}
            for key, values in self.histograms.items():
                if values:
                    import numpy as np
                    histogram_stats[key] = {
                        "count": len(values),
                        "mean": np.mean(values),
                        "p50": np.percentile(values, 50),
                        "p95": np.percentile(values, 95),
                        "p99": np.percentile(values, 99)
                    }

            return {
                "counters": dict(self.counters),
                "gauges": dict(self.gauges),
                "histograms": histogram_stats
            }


class InstrumentedGraphRAG:
    """Graph RAG with metrics instrumentation."""

    def __init__(
        self,
        graph_rag: CachedGraphRAG,
        metrics: MetricsCollector
    ):
        self.graph_rag = graph_rag
        self.metrics = metrics

    def generate(self, query: str, **kwargs) -> dict[str, Any]:
        """Generate with metrics collection."""
        self.metrics.increment_counter("graphrag_requests_total")

        with self.metrics.timer("graphrag_latency_seconds"):
            result = self.graph_rag.generate(query, **kwargs)

        # Track cache hit/miss
        if result.get("cached"):
            self.metrics.increment_counter("graphrag_cache_hits_total")
        else:
            self.metrics.increment_counter("graphrag_cache_misses_total")

        # Track retrieval metrics
        num_entities = len(result.get("retrieved_entities", []))
        self.metrics.observe_histogram(
            "graphrag_entities_retrieved",
            num_entities
        )

        # Track context size
        context = result.get("context")
        if context:
            context_text = context.to_text()
            self.metrics.observe_histogram(
                "graphrag_context_chars",
                len(context_text)
            )

        return result

228.8 Advanced Topics

228.8.1 Temporal Knowledge Graphs

Many knowledge domains involve temporal dynamics where facts hold only during certain time periods. Temporal knowledge graphs augment triples with temporal scopes, requiring specialized representation and retrieval methods.

from dataclasses import dataclass
from datetime import datetime
from typing import Any


@dataclass
class TemporalRelation:
    """A relation with temporal scope."""
    head: Entity
    relation_type: str
    tail: Entity
    valid_from: datetime | None = None
    valid_until: datetime | None = None
    confidence: float = 1.0

    def is_valid_at(self, timestamp: datetime) -> bool:
        """Check if relation is valid at given time."""
        if self.valid_from and timestamp < self.valid_from:
            return False
        if self.valid_until and timestamp > self.valid_until:
            return False
        return True


class TemporalKnowledgeGraph:
    """Knowledge graph with temporal reasoning."""

    def __init__(self):
        self.entities: dict[str, Entity] = {}
        self.temporal_relations: list[TemporalRelation] = []

    def add_temporal_relation(self, relation: TemporalRelation):
        """Add a temporally scoped relation."""
        self.temporal_relations.append(relation)

    def get_snapshot(self, timestamp: datetime) -> list[TemporalRelation]:
        """Get all relations valid at a specific time."""
        return [
            rel for rel in self.temporal_relations
            if rel.is_valid_at(timestamp)
        ]

    def get_entity_history(
        self,
        entity_id: str,
        relation_type: str | None = None
    ) -> list[tuple[TemporalRelation, str]]:
        """Get temporal history of an entity's relations."""
        entity = self.entities.get(entity_id)
        if not entity:
            return []

        history = []
        for rel in self.temporal_relations:
            if rel.head == entity or rel.tail == entity:
                if relation_type is None or rel.relation_type == relation_type:
                    direction = "outgoing" if rel.head == entity else "incoming"
                    history.append((rel, direction))

        # Sort by temporal validity
        history.sort(key=lambda x: x[0].valid_from or datetime.min)
        return history


class TemporalGraphRAG:
    """Graph RAG with temporal awareness."""

    def __init__(
        self,
        llm_client: Any,
        temporal_graph: TemporalKnowledgeGraph,
        embedding_model: Any
    ):
        self.llm = llm_client
        self.graph = temporal_graph
        self.embedding_model = embedding_model

    def generate(
        self,
        query: str,
        reference_time: datetime | None = None
    ) -> dict[str, Any]:
        """Generate with temporal context."""
        # Parse temporal expressions from query
        parsed_time = self._parse_temporal_expression(query, reference_time)

        # Get temporally valid snapshot
        if parsed_time:
            valid_relations = self.graph.get_snapshot(parsed_time)
        else:
            valid_relations = self.graph.temporal_relations

        # Build context from valid relations
        context_parts = []
        for rel in valid_relations[:50]:  # Limit context size
            temporal_qualifier = ""
            if rel.valid_from or rel.valid_until:
                start = rel.valid_from.strftime("%Y-%m-%d") if rel.valid_from else "?"
                end = rel.valid_until.strftime("%Y-%m-%d") if rel.valid_until else "present"
                temporal_qualifier = f" (valid: {start} to {end})"

            context_parts.append(
                f"{rel.head.name} --[{rel.relation_type}]--> {rel.tail.name}{temporal_qualifier}"
            )

        context_text = "\n".join(context_parts)

        prompt = f"""Answer the following question using the temporally-scoped
knowledge provided. Pay attention to the temporal validity of facts.

Temporal Knowledge:
{context_text}

Question: {query}

If the question involves a specific time period, ensure your answer reflects
what was true during that period."""

        response = self.llm.generate(user_prompt=prompt)

        return {
            "response": response,
            "reference_time": parsed_time,
            "relations_used": len(valid_relations)
        }

    def _parse_temporal_expression(
        self,
        query: str,
        default: datetime | None
    ) -> datetime | None:
        """Parse temporal expressions from query."""
        # Simple heuristic parsing - production systems would use
        # more sophisticated temporal expression recognition
        query_lower = query.lower()

        if "currently" in query_lower or "now" in query_lower:
            return datetime.now()
        if "2023" in query:
            return datetime(2023, 6, 15)
        if "2022" in query:
            return datetime(2022, 6, 15)
        if "last year" in query_lower:
            now = datetime.now()
            return datetime(now.year - 1, 6, 15)

        return default

228.8.2 Hybrid Vector-Graph Retrieval

Combining dense vector retrieval with graph-based retrieval leverages the complementary strengths of both approaches. Vector retrieval excels at semantic similarity matching, while graph retrieval captures structural and relational patterns.

from dataclasses import dataclass
from typing import Any
import numpy as np


@dataclass
class HybridRetrievalResult:
    """Result from hybrid retrieval."""
    entity_id: str
    entity: Entity
    vector_score: float
    graph_score: float
    combined_score: float


class HybridRetriever:
    """Combines vector and graph-based retrieval."""

    def __init__(
        self,
        entity_retriever: EntityRetriever,
        graph: KnowledgeGraph,
        graph_weight: float = 0.3,
        personalization_weight: float = 0.1
    ):
        self.entity_retriever = entity_retriever
        self.graph = graph
        self.graph_weight = graph_weight
        self.personalization_weight = personalization_weight

    def retrieve(
        self,
        query: str,
        seed_entities: list[str] | None = None,
        top_k: int = 10
    ) -> list[HybridRetrievalResult]:
        """Perform hybrid retrieval."""
        # Vector retrieval
        vector_results = self.entity_retriever.retrieve(query, top_k=top_k * 2)
        vector_scores = {r.entity_id: r.score for r in vector_results}

        # Graph-based scores using PageRank with personalization
        graph_scores = self._compute_personalized_pagerank(
            seed_entities or [r.entity_id for r in vector_results[:3]]
        )

        # Combine scores
        all_entity_ids = set(vector_scores.keys()) | set(graph_scores.keys())

        combined_results = []
        for entity_id in all_entity_ids:
            v_score = vector_scores.get(entity_id, 0)
            g_score = graph_scores.get(entity_id, 0)

            combined_score = (
                (1 - self.graph_weight) * v_score +
                self.graph_weight * g_score
            )

            entity = self.graph.entities.get(entity_id)
            if entity:
                combined_results.append(HybridRetrievalResult(
                    entity_id=entity_id,
                    entity=entity,
                    vector_score=v_score,
                    graph_score=g_score,
                    combined_score=combined_score
                ))

        # Sort by combined score
        combined_results.sort(key=lambda x: x.combined_score, reverse=True)
        return combined_results[:top_k]

    def _compute_personalized_pagerank(
        self,
        seed_entities: list[str],
        damping: float = 0.85,
        max_iterations: int = 100,
        tolerance: float = 1e-6
    ) -> dict[str, float]:
        """Compute personalized PageRank from seed entities."""
        entity_ids = list(self.graph.entities.keys())
        n = len(entity_ids)

        if n == 0:
            return {}

        id_to_idx = {eid: i for i, eid in enumerate(entity_ids)}

        # Build adjacency matrix
        adj = np.zeros((n, n))
        for rel in self.graph.relations:
            head_id = self.graph._entity_id(rel.head)
            tail_id = self.graph._entity_id(rel.tail)

            if head_id in id_to_idx and tail_id in id_to_idx:
                adj[id_to_idx[head_id], id_to_idx[tail_id]] = 1
                adj[id_to_idx[tail_id], id_to_idx[head_id]] = 1  # Undirected

        # Row normalize
        row_sums = adj.sum(axis=1, keepdims=True)
        row_sums[row_sums == 0] = 1  # Avoid division by zero
        transition = adj / row_sums

        # Personalization vector
        personalization = np.zeros(n)
        for seed_id in seed_entities:
            if seed_id in id_to_idx:
                personalization[id_to_idx[seed_id]] = 1.0
        if personalization.sum() > 0:
            personalization /= personalization.sum()
        else:
            personalization = np.ones(n) / n

        # Power iteration
        scores = np.ones(n) / n
        for _ in range(max_iterations):
            new_scores = (
                damping * transition.T @ scores +
                (1 - damping) * personalization
            )

            if np.abs(new_scores - scores).sum() < tolerance:
                break
            scores = new_scores

        return {entity_ids[i]: float(scores[i]) for i in range(n)}

228.8.3 Modular Multi-Step Construction with Compact Extraction Models

The knowledge graph construction machinery developed earlier in this chapter, spanning entity and relation extraction, coreference resolution, entity linking, and community detection, is often presented as a single monolithic extraction call. In practice the quality of a GraphRAG system depends far more on how carefully these stages are decomposed and composed than on the raw capacity of the language model that performs the inner extraction. RAGU, an open-source modular GraphRAG engine, makes this argument explicit and provides an implementation that pushes the entire pipeline onto a single GPU (Komarov et al. 2026).

The central design choice in RAGU is to separate entity and relation extraction from graph consolidation. Rather than asking one model to emit a clean graph in a single noisy pass, RAGU runs a two-stage extraction pipeline that first proposes candidate entities and relations and then refines them, followed by explicit deduplication, summarization, and community detection stages. This mirrors the pipeline structure assembled by hand across the earlier sections: extraction (see the discussion of large language models for knowledge extraction), consolidation through coreference and linking, and community summarization for global queries. Isolating these concerns makes each stage individually testable and lets the system recover from local extraction errors during consolidation, instead of propagating them into the final graph.

The thesis that motivates this decomposition concerns model size. The skills an in-pipeline language model actually needs are comprehension of a text chunk, extraction of the entities and relations it states, and reasoning over provided context. RAGU argues that these are language skills that grow only weakly with parameter count, so a compact domain-adapted model is sufficient for the inner LLM calls, provided the surrounding pipeline is engineered well. To test this, the authors train Meno-Lite-0.1, a 7B model specialized for the construction task. It outperforms the much larger Qwen2.5-32B on knowledge graph construction by 12.5 percent relative, measured as the harmonic mean of the construction metrics, while matching it on English GraphRAG benchmarks and showing strong retrieval on medical question answering. Because the compact model carries the extraction load, the whole system runs on a single GPU and ships as an installable package under a permissive license.

The practical takeaway sharpens the message of this chapter. GraphRAG quality is bottlenecked by pipeline engineering, the multi-step extraction and consolidation logic, more than by the size of the extraction model. That reframing is what makes local, cheap, and private GraphRAG deployment feasible: a modest domain-adapted model plus a disciplined pipeline can replace a large general-purpose model behind an API. The cell below is a compact conceptual walkthrough of that multi-step pipeline, working from a small set of triples “extracted” from a toy corpus through consolidation, community detection, and the contrast between a global and a local query.

import networkx as nx
from networkx.algorithms.community import greedy_modularity_communities

# Stage 1: triples "extracted" from a toy corpus by an inner LLM call.
# Some entities appear under aliased surface forms (J. Doe / Jane Doe,
# New York University / NYU), exactly the noise consolidation must fix.
raw_triples = [
    ("Jane Doe", "affiliated_with", "NYU"),
    ("J. Doe", "coauthored", "GraphNet"),
    ("Jane Doe", "advised_by", "Alan Roe"),
    ("Alan Roe", "affiliated_with", "New York University"),
    ("GraphNet", "cites", "TransE"),
    ("Bob Lin", "affiliated_with", "MIT"),
    ("Bob Lin", "coauthored", "VecStore"),
    ("Carol Ng", "affiliated_with", "MIT"),
    ("Carol Ng", "coauthored", "VecStore"),
    ("VecStore", "cites", "FAISS"),
]

# Stage 2: entity consolidation. A separate deduplication step merges
# aliased surface forms onto canonical entities before the graph is built.
alias_to_canonical = {
    "J. Doe": "Jane Doe",
    "New York University": "NYU",
}
def canon(name):
    return alias_to_canonical.get(name, name)

triples = [(canon(h), r, canon(t)) for h, r, t in raw_triples]

# Stage 3: build the consolidated knowledge graph.
G = nx.Graph()
for head, rel, tail in triples:
    G.add_edge(head, tail, relation=rel)

print(f"raw entities:          {len({e for h, _, t in raw_triples for e in (h, t)})}")
print(f"consolidated entities: {G.number_of_nodes()}")

# Stage 4: community detection groups densely connected entities into
# coherent units for global summarization.
communities = list(greedy_modularity_communities(G))

# Global query: one summary per community (a corpus-level overview).
print("\nGlobal query (per-community overview):")
for i, community in enumerate(communities):
    members = sorted(community)
    rels = {d["relation"] for u, v, d in G.edges(members, data=True)
            if u in community and v in community}
    print(f"  community {i}: {members}")
    print(f"    relations: {sorted(rels)}")

# Local query: the immediate neighborhood of a single focus entity.
focus = "Jane Doe"
print(f"\nLocal query (neighborhood of {focus!r}):")
for neighbor in sorted(G.neighbors(focus)):
    print(f"  {focus} --[{G[focus][neighbor]['relation']}]--> {neighbor}")

raw entities:          12
consolidated entities: 10

Global query (per-community overview):
  community 0: ['Bob Lin', 'Carol Ng', 'FAISS', 'MIT', 'VecStore']
    relations: ['affiliated_with', 'cites', 'coauthored']
  community 1: ['Alan Roe', 'Jane Doe', 'NYU']
    relations: ['advised_by', 'affiliated_with']
  community 2: ['GraphNet', 'TransE']
    relations: ['cites']

Local query (neighborhood of 'Jane Doe'):
  Jane Doe --[advised_by]--> Alan Roe
  Jane Doe --[coauthored]--> GraphNet
  Jane Doe --[affiliated_with]--> NYU

The demo compresses the full engine into a few lines, but it exposes the load-bearing idea: the alias merge in stage 2 is what lets community detection in stage 4 place Jane Doe and her advisor in the same cluster, and it is the pipeline, not the extractor, that does that work. A production deployment would call a compact model such as Meno-Lite for the extraction in stage 1 and reuse the community and neighborhood structure to answer global and local queries at scale, the same global versus local distinction developed in the community detection and context assembly sections above. The block below sketches the real RAGU API for reference.

# requires the graph_ragu package + an LLM/embedder backend and a GPU; shown, not executed
# pip install graph_ragu   (MIT license, runs on a single GPU)
# companion 7B model: bond005/meno-lite on Hugging Face
# source: github.com/RaguTeam/RAGU
import asyncio
from graph_ragu import (
    KnowledgeGraph,
    LocalSearchEngine,
    GlobalSearchEngine,
)

knowledge_graph = KnowledgeGraph(
    llm=llm,                          # e.g. a Meno-Lite backend
    embedder=embedder,
    chunker=chunker,
    artifact_extractor=artifact_extractor,
)

# multi-step extraction + consolidation + community detection over the corpus
asyncio.run(knowledge_graph.build_from_docs(docs))

# local query: reason over the neighborhood of the matched entities
local_engine = LocalSearchEngine(knowledge_graph)
local_answer = asyncio.run(local_engine.a_query("What did Jane Doe work on?"))

# global query: synthesize across community summaries
global_engine = GlobalSearchEngine(knowledge_graph)
global_answer = asyncio.run(
    global_engine.a_search("What themes span the whole corpus?")
)

228.9 Zero-Token Memory Operations for Agents

Every construction pipeline developed so far in this chapter spends language model calls on the graph itself. Entity and relation extraction runs a model over each chunk, coreference resolution and entity linking run further passes, and community summarization runs one more. That expenditure is justified when the corpus is written once and queried many times, because the extraction cost amortizes. It is much harder to justify for an agent whose memory grows with every interaction, since each new turn triggers a fresh write and the amortization never arrives. Zero-Mem takes the extreme position on this question and asks whether structured memory access requires generation at all (Xiao et al. 2026). Its answer is that no step outside final question answering needs to invoke a language model or consume language model tokens, and that the entity graph machinery of this chapter is exactly what makes the deterministic alternative work.

228.9.1 A Token Accounting Model for Agent Memory

Fix an agent that has recorded \(N\) interaction traces \(\mathcal{T} = \{t_1, \dots, t_N\}\) and must serve \(Q\) queries against them. A generative memory system spends language model tokens in three places. The write path applies an operator \(\mathcal{W}\) to each incoming trace, extracting entities, distilling facts, and merging them into whatever record structure the system maintains, at a cost of \(c_w\) tokens per interaction. The read path applies a mediation operator \(\mathcal{R}\) to each query, rewriting it, planning a retrieval, or judging candidate records, at a cost of \(c_r\) tokens per query. The reader finally answers each query at a cost of \(c_a\) tokens, counting both the retrieved context it consumes and the answer it emits. Total language model token consumption is therefore

\[ C_{\text{gen}}(N, Q) = N c_w + Q c_r + Q c_a . \]

Zero-token memory operations mean that \(\mathcal{W}\) and \(\mathcal{R}\) are implemented without invoking a language model, so the first two terms vanish identically:

\[ C_{\text{zero}}(N, Q) = Q c_a . \]

The relative saving is

\[ \rho(N, Q) = 1 - \frac{C_{\text{zero}}}{C_{\text{gen}}} = 1 - \frac{Q c_a}{N c_w + Q (c_r + c_a)} . \]

Two regimes matter, and they behave differently. In the first, the query workload is fixed at \(Q = Q_0\) while the interaction history keeps growing. Then

\[ 1 - \rho(N, Q_0) = \frac{Q_0 c_a}{N c_w + Q_0 (c_r + c_a)} = \Theta\!\left(\frac{1}{N}\right), \]

so \(\rho \to 1\) and the saving approaches the whole token budget. This is the long-lived assistant that accumulates history far faster than it is interrogated, and it is the case where generative memory is worst off, because it pays \(c_w\) for material that may never be read.

In the second regime the workload scales with the history, \(Q = \alpha N\) for a fixed query-to-interaction ratio \(\alpha > 0\). The factors of \(N\) cancel and the saving becomes a constant independent of history length,

\[ \rho_\infty(\alpha) = 1 - \frac{\alpha c_a}{c_w + \alpha (c_r + c_a)} . \]

Differentiating, \(\rho_\infty\) is strictly decreasing in \(\alpha\), since a query-heavy workload dilutes the fixed per-interaction write saving. Taking \(\alpha \to \infty\) gives the floor

\[ \lim_{\alpha \to \infty} \rho_\infty(\alpha) = 1 - \frac{c_a}{c_r + c_a} = \frac{c_r}{c_r + c_a} > 0 . \]

This is the load-bearing structural result. Even for an agent queried far more often than it is written to, where the write saving is negligible, eliminating read mediation alone still removes a fixed fraction \(c_r / (c_r + c_a)\) of the token budget. There is no workload at which zero-token memory operations stop paying, because \(c_w > 0\) and \(c_r > 0\) make \(\rho > 0\) for every finite \(N\) and \(Q\). The crossover question is therefore not whether but by how much, and the answer depends only on the ratio of mediation cost to answering cost.

228.9.2 Encoder Compute Is Accounted Separately, Not Eliminated

The claim above is about language model tokens, and it would be dishonest to present it as a claim about total arithmetic. Zero-Mem still embeds traces and queries with a text encoder, and it still builds and traverses an index. The paper is explicit that encoder computation is accounted for separately, and the model should be too. Let \(\ell_x\) be the encoder tokens per stored trace, \(\ell_q\) the encoder tokens per query, and \(\ell_g\) the additional encoder tokens per trace charged to building the graph and hierarchy views. Write \(\kappa\) for the cost of one encoder token expressed in language model token equivalents, a number well below one because encoders are small and run in a single forward pass with no autoregressive decode. The two systems then cost

\[ T_{\text{gen}} = N c_w + Q(c_r + c_a) + \kappa \left( N \ell_x + Q \ell_q \right), \]

\[ T_{\text{zero}} = Q c_a + \kappa \left( N \ell_x + Q \ell_q + N \ell_g \right). \]

Both systems pay the base encoding term, so it cancels in the comparison, leaving

\[ T_{\text{gen}} - T_{\text{zero}} = N c_w + Q c_r - \kappa N \ell_g . \]

Zero-token memory wins on total accounted cost exactly when

\[ c_w + \frac{Q}{N} c_r > \kappa \, \ell_g , \]

which is the honest crossover condition. It fails only if an encoder token were to cost more than a language model token by a wide margin, which inverts the actual hardware economics. The cell below instantiates this with concrete parameters and reports the break-even value of \(\kappa\).

228.9.3 Preserving Traces as a Rate-Distortion Choice

The second half of the argument concerns what generative memory throws away. A write operator \(\mathcal{W}\) maps a trace \(X\) to a record \(M = \mathcal{W}(X)\) at rate \(R = I(X; M)\) bits. Because \(M\) is a deterministic function of \(X\) and answering proceeds through \(M\), the Markov chain \(X \to M \to \hat{A}\) holds and the data processing inequality gives \(I(A; M) \le I(A; X)\) for any answer variable \(A\). Evidence dropped at write time cannot be recovered by any later retrieval, however clever. This is not a criticism of summarization as such, it is a statement that the compression is irreversible.

The sharper point is when the compression is chosen. Let \(d(x, q, \hat{a})\) be the distortion of answering query \(q\) about trace content \(x\). A generative memory system must commit to a single \(\mathcal{W}\) before the query distribution is realized, so it solves

\[ D_{\text{write}} = \min_{\mathcal{W} : R(\mathcal{W}) \le R} \; \mathbb{E}_{q} \, \mathbb{E}_{x} \; d\big(x, q, \mathcal{W}(x)\big), \]

a single compressor that must serve every query it will ever see. Preserving original traces sets \(M = X\), paying the full rate \(H(X)\) in storage, and defers compression to query time, where the context window budget is spent by a query-dependent selector \(\mathcal{W}_q\):

\[ D_{\text{read}} = \mathbb{E}_{q} \; \min_{\mathcal{W}_q : R(\mathcal{W}_q) \le R} \; \mathbb{E}_{x} \; d\big(x, q, \mathcal{W}_q(x)\big). \]

Since the minimum of an expectation is never below the expectation of the pointwise minimum, \(D_{\text{read}} \le D_{\text{write}}\), with equality only in the degenerate case where one compressor is simultaneously optimal for every query. Deferring the compression is therefore never worse in expected distortion at the same context budget. What it costs is storage and index size, \(H(X)\) rather than \(R\) bits per trace, plus the encoder passes accounted above. That is the real tradeoff, and it is a favorable one whenever disk is cheaper than lost evidence.

228.9.4 Two Views over the Same Traces

Zero-Mem organizes the preserved traces in two complementary ways and never rewrites them. The first view is an entity-context graph, which is the construction of the section on knowledge graph construction with the language model removed from the extraction step. Let \(V_E\) be the entity vocabulary and let \(\iota(t) \subseteq V_E\) be the entities appearing in trace \(t\), obtained by deterministic surface matching against the vocabulary rather than by generation. Edge weights count co-mentions,

\[ A_{uv} = \big| \{ t \in \mathcal{T} : u, v \in \iota(t), \; u \ne v \} \big| , \]

giving the column-stochastic transition matrix \(P = A D^{-1}\) with \(D_{vv} = \sum_u A_{uv}\). For a query \(q\) with anchor entities \(Q_e \subseteq V_E\), personalized PageRank from each anchor \(e\) solves the linear system introduced earlier in this chapter,

\[ \pi_e = \alpha r_e + (1 - \alpha) P \pi_e \quad \Longleftrightarrow \quad \pi_e = \alpha \left( I - (1 - \alpha) P \right)^{-1} r_e , \]

where \(r_e\) is the indicator of \(e\) and \(\alpha\) is the restart probability. The relational score of a trace is the geometric mean over anchors of its best entity match,

\[ s_G(t \mid q) = \left( \prod_{e \in Q_e} \max_{u \in \iota(t)} \pi_e(u) \right)^{1 / |Q_e|} . \]

The geometric mean is the essential choice. An arithmetic mean rewards a trace that sits adjacent to one anchor and nowhere near the others, which is precisely the failure mode on multi-hop questions, since almost every trace mentioning a popular anchor would score well. The geometric mean is zero unless the trace is close to every anchor, so it selects traces that lie on a connecting path, which is what “recovering supporting relations” means operationally.

The second view is a temporal hierarchy over sessions and turns. Let \(\sigma(t)\) be the session index of trace \(t\) and \(\tau(t)\) its turn index inside that session, and let \(E_s = \bigcup_{\sigma(t) = s} \iota(t)\) be the entity set of session \(s\). Session coverage is \(c_s = |Q_e \cap E_s| / |Q_e|\), the anchor session is the most recent maximally covering one,

\[ \sigma^\star = \max \left\{ s : c_s = \max_{s'} c_{s'} \right\}, \]

and \(\pi_s\) is the turn in session \(s\) with the largest anchor overlap. The locality score multiplies coverage, session recency, and within-session proximity:

\[ s_T(t \mid q) = c_{\sigma(t)} \cdot \exp\!\left( - \frac{ | \sigma^\star - \sigma(t) | }{ \tau_0 } \right) \cdot \exp\!\left( - \frac{ ( \tau(t) - \pi_{\sigma(t)} )^2 }{ 2 \sigma_0^2 } \right) . \]

The first exponential encodes session state and recency, the second encodes conversational locality inside a session. Both scores are normalized to unit maximum over \(\mathcal{T}\) so that they are comparable, and the retrieval score is a convex combination

\[ s(t \mid q) = \lambda(q) \, \hat{s}_G(t \mid q) + \big( 1 - \lambda(q) \big) \, \hat{s}_T(t \mid q) . \]

228.9.5 Deriving the Query-Dependent View Weight

The weight \(\lambda(q)\) is where the coordination happens, and it can be derived rather than tuned. Model relevance as a two-component mixture: a latent variable \(Z \in \{G, T\}\) selects which view is responsible for the evidence a query needs, and

\[ p(t \text{ relevant} \mid q) = \pi_G(q) \, p_G(t \mid q) + \big(1 - \pi_G(q)\big) \, p_T(t \mid q) . \]

Ranking by this posterior is Bayes-optimal under the mixture model. If the two normalized scores are calibrated so that \(\hat{s}_G \propto p_G\) and \(\hat{s}_T \propto p_T\), then matching the convex combination to the mixture gives

\[ \lambda^\star(q) = \pi_G(q) = P(Z = G \mid q), \]

so the optimal weight is not a hyperparameter at all, it is the posterior probability that the query is relational.

Estimating that posterior without a language model requires an observable statistic that separates the two cases. The right one is joint coverage: whether any single stored trace already contains all the anchors. Define

\[ c^\star(q) = \max_{t \in \mathcal{T}} \frac{ | Q_e \cap \iota(t) | }{ | Q_e | }, \qquad \delta(q) = 1 - c^\star(q) . \]

If \(\delta(q) = 0\) then some single interaction already witnesses all the anchors together, the evidence is local, and the surrounding conversational context is what the reader needs, so \(Z = T\). If \(\delta(q) > 0\) then no single interaction witnesses them jointly, the answer must be assembled by following connections across interactions, so \(Z = G\). Taking a logistic link on this deficit,

\[ \lambda^\star(q) = \sigma\big( \beta ( \delta(q) - \delta_0 ) \big), \qquad \sigma(z) = \frac{1}{1 + e^{-z}}, \]

with \(\beta\) a sharpness and \(\delta_0\) a threshold placed between the fully covered and partially covered cases. For two-anchor queries \(\delta(q) \in \{0, 1/2\}\), and with \(\beta = 8\), \(\delta_0 = 1/4\) the weight takes the values \(\sigma(-2) \approx 0.12\) and \(\sigma(2) \approx 0.88\), a soft switch rather than a hard one. Computing \(c^\star(q)\) costs a single pass over the inverted index from entities to traces, which is why the coordination step consumes no language model tokens.

flowchart TB
    I["Interaction traces stored verbatim"]
    E["Deterministic entity tagging by surface match"]
    G["Entity context graph"]
    H["Temporal hierarchy over sessions and turns"]
    Q["Query with anchor entities"]
    W["View weight from joint coverage deficit"]
    SG["Relational score by personalized PageRank"]
    ST["Locality score by recency and turn window"]
    C["Weighted merge and top k selection"]
    F["Consistency filter discards conflicting traces"]
    R["Final QA reader is the only LLM call"]
    I --> E
    E --> G
    I --> H
    Q --> W
    Q --> SG
    Q --> ST
    G --> SG
    H --> ST
    SG --> C
    ST --> C
    W --> C
    C --> F
    F --> R

228.9.6 Deterministic Calibration as a Consistency Filter

Preserving raw traces has a cost the summarizing systems partly avoid: contradictions survive. A trace recorded in session three may assert a status that a trace in session nine overturns, and both are retrieved. Zero-Mem resolves this deterministically before the reader sees anything, and the resolution has a clean combinatorial form.

Let \(\mathcal{S}_k\) be the top \(k\) traces under \(s(\cdot \mid q)\), and suppose each trace carries claims of the form (key, value). Define the conflict relation \(t \sim t'\) when the two traces assert different values for the same key. The conflict graph \(H = (\mathcal{S}_k, \sim)\) makes the calibration objective a maximum weight independent set,

\[ \mathcal{S}^\star = \arg\max_{\substack{U \subseteq \mathcal{S}_k \\ U \text{ independent in } H}} \; \sum_{t \in U} s(t \mid q) , \]

which is NP-hard on general graphs. It is not general here. Partition \(\mathcal{S}_k\) by key, and within a key partition further by asserted value into parts \(V_1, \dots, V_m\). Conflict edges join traces in different parts and never join traces in the same part, so the subgraph on each key is complete multipartite. An independent set in a complete multipartite graph is exactly a subset of a single part, and there are no edges between distinct keys, so the problem separates:

\[ \mathcal{S}^\star = \bigsqcup_{\text{keys } \kappa} \; \arg\max_{V \in \{V_1^\kappa, \dots, V_{m_\kappa}^\kappa\}} \; \sum_{t \in V} s(t \mid q) . \]

The NP-hard objective collapses to one argmax per key, computable in \(O(|\mathcal{S}_k|)\) time with a single dictionary pass and no model call. The retained set is internally consistent by construction, and because the reader is restricted to it, the answer is grounded in surviving traces rather than in an intermediate record that has already smoothed the disagreement away.

Python

import numpy as np


def normalize(v):
    m = float(np.max(v))
    return v / m if m > 0 else v


def view_weight(deficit, beta=8.0, delta0=0.25):
    """Mixture prior P(Z = G | q) estimated from the joint coverage deficit."""
    return 1.0 / (1.0 + np.exp(-beta * (deficit - delta0)))


def two_view_score(s_graph, s_temporal, deficit):
    lam = view_weight(deficit)
    return lam * normalize(s_graph) + (1.0 - lam) * normalize(s_temporal), lam


s_g = np.array([0.90, 0.20, 0.70, 0.10])   # relational proximity per trace
s_t = np.array([0.10, 0.80, 0.20, 0.90])   # temporal locality per trace

for deficit, name in [(0.0, "anchors share a trace"), (0.5, "anchors never co-occur")]:
    s, lam = two_view_score(s_g, s_t, deficit)
    print(f"{name:<24} lambda={lam:.3f}  ranking={np.argsort(-s).tolist()}")

anchors share a trace    lambda=0.119  ranking=[3, 1, 2, 0]
anchors never co-occur   lambda=0.881  ranking=[0, 2, 1, 3]

Julia

normalize(v) = maximum(v) > 0 ? v ./ maximum(v) : v

view_weight(deficit; beta = 8.0, delta0 = 0.25) =
    1.0 / (1.0 + exp(-beta * (deficit - delta0)))

function two_view_score(s_graph, s_temporal, deficit)
    lam = view_weight(deficit)
    return lam .* normalize(s_graph) .+ (1.0 - lam) .* normalize(s_temporal), lam
end

s_g = [0.90, 0.20, 0.70, 0.10]
s_t = [0.10, 0.80, 0.20, 0.90]

for (deficit, name) in [(0.0, "anchors share a trace"),
                        (0.5, "anchors never co-occur")]
    s, lam = two_view_score(s_g, s_t, deficit)
    println(rpad(name, 24), " lambda=", round(lam, digits = 3),
            "  ranking=", sortperm(s, rev = true))
end

Rust

fn normalize(v: &[f64]) -> Vec<f64> {
    let m = v.iter().cloned().fold(f64::MIN, f64::max);
    if m > 0.0 { v.iter().map(|x| x / m).collect() } else { v.to_vec() }
}

fn view_weight(deficit: f64, beta: f64, delta0: f64) -> f64 {
    1.0 / (1.0 + (-beta * (deficit - delta0)).exp())
}

fn two_view_score(s_graph: &[f64], s_temporal: &[f64], deficit: f64) -> (Vec<f64>, f64) {
    let lam = view_weight(deficit, 8.0, 0.25);
    let (g, t) = (normalize(s_graph), normalize(s_temporal));
    let s = g.iter().zip(t.iter()).map(|(a, b)| lam * a + (1.0 - lam) * b).collect();
    (s, lam)
}

fn main() {
    let s_g = [0.90, 0.20, 0.70, 0.10];
    let s_t = [0.10, 0.80, 0.20, 0.90];
    for (deficit, name) in [(0.0, "anchors share a trace"),
                            (0.5, "anchors never co-occur")] {
        let (s, lam) = two_view_score(&s_g, &s_t, deficit);
        let mut order: Vec<usize> = (0..s.len()).collect();
        order.sort_by(|&i, &j| s[j].partial_cmp(&s[i]).unwrap());
        println!("{:<24} lambda={:.3}  ranking={:?}", name, lam, order);
    }
}

228.9.7 A Working Zero-Token Memory Index

The cell below builds the whole apparatus over synthetic multi-session interaction traces without a single model call. Entities are tagged by surface matching, the entity-context graph is a co-mention matrix, the temporal hierarchy is a session and turn indexing, retrieval is the two-view combination derived above, and calibration is the per-key argmax. The corpus is generated with twelve topic clusters of four entities each, so that base sessions never mix clusters, and then a set of cross-session facts is planted: a rare bridge entity is inserted into two traces in different sessions, linking two entities that never co-occur anywhere. Relational questions ask how such a pair is connected, with the two planted traces as ground truth. Temporal questions ask what surrounded the last discussion of an anchor pair, with a three-turn window in the most recent covering session as ground truth. The two question families are constructed so that each single view is systematically wrong on the other family, which is what makes the ablation informative.

import numpy as np
import matplotlib.pyplot as plt
from collections import defaultdict

rng = np.random.default_rng(469)

# ---------------------------------------------------------------- synthetic traces
N_ENT, N_SESS, TURNS, N_CLUST = 48, 60, 8, 12
entities = [f"e{i:02d}" for i in range(N_ENT)]
clusters = [entities[c * 4:(c + 1) * 4] for c in range(N_CLUST)]
clust_of = {e: c for c, cl in enumerate(clusters) for e in cl}

traces = []
for s in range(N_SESS):
    cl = clusters[s % N_CLUST]
    for t in range(TURNS):
        k = int(rng.integers(2, 4))
        ents = set(rng.choice(cl, size=k, replace=False).tolist())
        traces.append({"sid": s, "tid": t, "ents": ents})

n_traces = len(traces)

# plant cross-session relational facts: a rare bridge entity r links a and b,
# which never co-occur in any single trace, through two traces in different sessions
N_BRIDGE = 24
bridges = [f"r{i:02d}" for i in range(N_BRIDGE)]
entities = entities + bridges
planted = []


def cooccur(a, b):
    return any(a in tr["ents"] and b in tr["ents"] for tr in traces)


base = [f"e{i:02d}" for i in range(N_ENT)]
attempts = 0
while len(planted) < N_BRIDGE and attempts < 5000:
    attempts += 1
    a, b = rng.choice(N_ENT, size=2, replace=False).tolist()
    a, b = base[a], base[b]
    if clust_of[a] == clust_of[b] or cooccur(a, b):
        continue
    i, j = rng.integers(0, n_traces), rng.integers(0, n_traces)
    if traces[i]["sid"] == traces[j]["sid"]:
        continue
    if b in traces[i]["ents"] or a in traces[j]["ents"]:
        continue
    r = bridges[len(planted)]
    traces[i]["ents"] |= {a, r}
    traces[j]["ents"] |= {b, r}
    planted.append({"a": a, "b": b, "r": r, "gold": {int(i), int(j)}})

N_ENT = len(entities)
sess_ents = defaultdict(set)
for i, tr in enumerate(traces):
    sess_ents[tr["sid"]] |= tr["ents"]

# ---------------------------------------------------------------- entity-context graph
idx = {e: i for i, e in enumerate(entities)}
A = np.zeros((N_ENT, N_ENT))
for tr in traces:
    es = sorted(tr["ents"])
    for a in es:
        for b in es:
            if a != b:
                A[idx[a], idx[b]] += 1.0
col = A.sum(axis=0)
col[col == 0] = 1.0
P = A / col  # column-stochastic transition matrix


def ppr(seeds, alpha=0.50, iters=80):
    """Personalized PageRank by power iteration, no model call involved."""
    r = np.zeros(N_ENT)
    for e in seeds:
        r[idx[e]] = 1.0
    r /= max(r.sum(), 1e-12)
    x = r.copy()
    for _ in range(iters):
        x_new = (1 - alpha) * (P @ x) + alpha * r
        if np.abs(x_new - x).sum() < 1e-10:
            x = x_new
            break
        x = x_new
    return x


def relational_scores(qents):
    # one personalized vector per anchor; a trace scores highly only if it is close
    # to EVERY anchor, hence the geometric mean over anchors of its best entity match
    vecs = [ppr([e]) for e in sorted(qents)]
    s = np.zeros(n_traces)
    for i, tr in enumerate(traces):
        cols = [idx[e] for e in tr["ents"]]
        s[i] = np.exp(np.mean([np.log(v[cols].max() + 1e-12) for v in vecs]))
    return s / max(s.max(), 1e-12)


# ---------------------------------------------------------------- temporal hierarchy
TAU, SIGMA = 2.0, 1.0


def coverage(qents):
    return {s: len(qents & sess_ents[s]) / len(qents) for s in range(N_SESS)}


def joint_coverage(qents):
    """Largest fraction of the anchor set observed inside a SINGLE trace."""
    return max(len(qents & tr["ents"]) / len(qents) for tr in traces)


def temporal_scores(qents):
    cov = coverage(qents)
    c_max = max(cov.values())
    anchor = max([s for s in cov if cov[s] >= c_max - 1e-9])
    pivot = {}
    for s in range(N_SESS):
        best_t, best_o = 0, -1
        for tr in traces:
            if tr["sid"] != s:
                continue
            o = len(qents & tr["ents"])
            if o > best_o:
                best_o, best_t = o, tr["tid"]
        pivot[s] = best_t
    s_arr = np.zeros(n_traces)
    for i, tr in enumerate(traces):
        s = tr["sid"]
        rec = np.exp(-abs(anchor - s) / TAU)
        loc = np.exp(-((tr["tid"] - pivot[s]) ** 2) / (2 * SIGMA**2))
        s_arr[i] = cov[s] * rec * loc
    return s_arr / max(s_arr.max(), 1e-12), c_max


BETA, DELTA0 = 8.0, 0.25


def view_weight(c_max):
    return 1.0 / (1.0 + np.exp(-BETA * ((1.0 - c_max) - DELTA0)))


# ---------------------------------------------------------------- query construction
trace_by_sid = defaultdict(list)
for i, tr in enumerate(traces):
    trace_by_sid[tr["sid"]].append(i)

queries = []
# relational: the two anchors never co-occur, so the answer must span sessions
for p in planted:
    if cooccur(p["a"], p["b"]):
        continue
    queries.append({"kind": "relational", "ents": {p["a"], p["b"]}, "gold": p["gold"]})

# temporal: the turn window around the last session that fully covers the anchor set
n_rel = len(queries)
for i, tr in enumerate(traces):
    ents_i = sorted(e for e in tr["ents"] if e.startswith("e"))
    if len(ents_i) < 2:
        continue
    qents = set(ents_i[:2])
    covering = [s for s in range(N_SESS) if qents <= sess_ents[s]]
    if len(covering) < 3:
        continue
    anchor = max(covering)
    best_t, best_o = 0, -1
    for j in trace_by_sid[anchor]:
        o = len(qents & traces[j]["ents"])
        if o > best_o:
            best_o, best_t = o, traces[j]["tid"]
    gold = {j for j in trace_by_sid[anchor] if abs(traces[j]["tid"] - best_t) <= 1}
    queries.append({"kind": "temporal", "ents": qents, "gold": gold})
    if len(queries) - n_rel >= 40:
        break

n_tmp = len(queries) - n_rel

# ---------------------------------------------------------------- ablation
K = 5
_cache = {}


def views(qents):
    key = frozenset(qents)
    if key not in _cache:
        _cache[key] = (relational_scores(qents), temporal_scores(qents)[0],
                       view_weight(joint_coverage(qents)))
    return _cache[key]


def evaluate(mode):
    out, lams = defaultdict(list), []
    for q in queries:
        sg, st, lam_star = views(q["ents"])
        lam = {"graph": 1.0, "temporal": 0.0, "fixed": 0.5, "adaptive": lam_star}[mode]
        lams.append(lam)
        s = lam * sg + (1 - lam) * st
        ranked = np.argsort(-s)
        rec = len(set(ranked[:K].tolist()) & q["gold"]) / len(q["gold"])
        rr = 0.0
        for rank, i in enumerate(ranked[:50], start=1):
            if i in q["gold"]:
                rr = 1.0 / rank
                break
        out[q["kind"]].append((rec, rr))
        out["all"].append((rec, rr))
    return out, float(np.mean(lams))


rows = []
for mode in ["graph", "temporal", "fixed", "adaptive"]:
    out, mlam = evaluate(mode)
    rows.append({"mode": mode,
                 "rel_rec": np.mean([r for r, _ in out["relational"]]),
                 "tmp_rec": np.mean([r for r, _ in out["temporal"]]),
                 "all_rec": np.mean([r for r, _ in out["all"]]),
                 "all_mrr": np.mean([m for _, m in out["all"]]),
                 "lam": mlam})

label = {"graph": "entity-graph only (lam=1)", "temporal": "temporal only (lam=0)",
         "fixed": "fixed blend (lam=0.5)", "adaptive": "two-view adaptive lam(q)"}
print(f"queries: {n_rel} relational, {n_tmp} temporal, {n_traces} traces, "
      f"{N_SESS} sessions")
print()
hdr = (f"{'retrieval view':<28}{'R@5 rel':>9}{'R@5 tmp':>9}"
       f"{'R@5 all':>9}{'MRR':>8}{'mean lam':>10}")
print(hdr)
print("-" * len(hdr))
for r in rows:
    print(f"{label[r['mode']]:<28}{r['rel_rec']:>9.3f}{r['tmp_rec']:>9.3f}"
          f"{r['all_rec']:>9.3f}{r['all_mrr']:>8.3f}{r['lam']:>10.3f}")

# ---------------------------------------------------------------- calibration
# every trace records a status claim about its most salient entity, and a fraction of
# the records are stale, so the retrieved set can hold mutually contradictory traces
P_STALE = 0.30
truth, claims = {}, {}
for i, tr in enumerate(traces):
    e = sorted(x for x in tr["ents"] if x.startswith("e"))[0]
    truth[e] = "active"
    claims[i] = (e, "stale" if rng.random() < P_STALE else "active")


def calibrate(cands, scores):
    """The conflict graph is complete multipartite within each key and disconnected
    across keys, so maximum weight independent set reduces to one argmax per key."""
    support = defaultdict(lambda: defaultdict(float))
    for i in cands:
        k, v = claims[i]
        support[k][v] += scores[i]
    keep, drop = [], []
    for i in cands:
        k, v = claims[i]
        best = max(support[k], key=lambda u: support[k][u])
        (keep if v == best else drop).append(i)
    return keep, drop, support


raw_ok = cal_ok = n_drop = n_cand = n_conflict = 0
for q in queries:
    sg, st, lam = views(q["ents"])
    s = lam * sg + (1 - lam) * st
    cands = np.argsort(-s)[:8].tolist()
    key, v_raw = claims[cands[0]]
    raw_ok += int(v_raw == truth[key])
    keep, drop, support = calibrate(cands, s)
    n_drop += len(drop)
    n_cand += len(cands)
    n_conflict += int(len(support[key]) > 1)
    v_cal = max(support[key], key=lambda u: support[key][u])
    cal_ok += int(v_cal == truth[key])

n_q = len(queries)
print()
print("deterministic calibration over the top-8 retrieved traces per query")
print(f"  candidate traces examined:        {n_cand}")
print(f"  queries with a conflicting key:   {n_conflict} of {n_q}")
print(f"  traces discarded as conflicting:  {n_drop} ({100 * n_drop / n_cand:.1f}%)")
print(f"  claim accuracy, top trace only:   {raw_ok / n_q:.3f}")
print(f"  claim accuracy, after filtering:  {cal_ok / n_q:.3f}")

# ---------------------------------------------------------------- token cost model
c_w, c_r, c_a = 900.0, 700.0, 1500.0
kappa, L_g = 0.02, 400.0
Nv = np.arange(10, 2001, 10)
Q_fixed, alpha = 200.0, 0.5
gen_fixed = Nv * c_w + Q_fixed * (c_r + c_a)
zero_fixed = np.full_like(Nv, Q_fixed * c_a, dtype=float)
gen_prop = Nv * c_w + alpha * Nv * (c_r + c_a)
zero_prop = alpha * Nv * c_a
rho_fixed = 1 - zero_fixed / gen_fixed
rho_prop = 1 - zero_prop / gen_prop
rho_asym = 1 - alpha * c_a / (c_w + alpha * c_r + alpha * c_a)

print()
print("token cost model  (c_write=900, c_read=700, c_answer=1500 tokens)")
print(f"{'N':>6}{'gen (Q=200)':>14}{'zero (Q=200)':>14}{'saving':>9}"
      f"{'gen (Q=N/2)':>14}{'zero (Q=N/2)':>14}{'saving':>9}")
for N in [50, 200, 1000, 2000]:
    j = int(np.where(Nv == N)[0][0])
    print(f"{N:>6}{gen_fixed[j]:>14,.0f}{zero_fixed[j]:>14,.0f}"
          f"{100 * rho_fixed[j]:>8.1f}%{gen_prop[j]:>14,.0f}{zero_prop[j]:>14,.0f}"
          f"{100 * rho_prop[j]:>8.1f}%")
print(f"asymptotic saving at Q = N/2: {100 * rho_asym:.1f}%")
print(f"saving floor as Q/N grows without bound: {100 * c_r / (c_r + c_a):.1f}%")
print(f"encoder crossover: LLM-token-equivalents avoided per interaction = "
      f"{c_w + alpha * c_r:.0f}, extra index encoding = {kappa * L_g:.1f}; "
      f"break-even needs kappa > {(c_w + alpha * c_r) / L_g:.2f}")

# ---------------------------------------------------------------- figure
fig, ax = plt.subplots(1, 3, figsize=(15, 4.2))
ax[0].plot(Nv, gen_fixed / 1e6, lw=2, label="generative memory (Q=200)")
ax[0].plot(Nv, zero_fixed / 1e6, lw=2, label="zero-token memory (Q=200)")
ax[0].plot(Nv, gen_prop / 1e6, lw=2, ls="--", label="generative memory (Q=N/2)")
ax[0].plot(Nv, zero_prop / 1e6, lw=2, ls="--", label="zero-token memory (Q=N/2)")
ax[0].set_xlabel("interactions N")
ax[0].set_ylabel("cumulative LLM tokens (millions)")
ax[0].set_title("Token cost of memory operations")
ax[0].legend(fontsize=8)
ax[0].grid(alpha=0.3)

ax[1].plot(Nv, 100 * rho_fixed, lw=2, label="Q = 200 (fixed workload)")
ax[1].plot(Nv, 100 * rho_prop, lw=2, label="Q = N/2 (proportional)")
ax[1].axhline(100 * rho_asym, color="gray", ls=":", lw=1.5,
              label=f"asymptote {100 * rho_asym:.1f}%")
ax[1].set_xlabel("interactions N")
ax[1].set_ylabel("token saving (percent)")
ax[1].set_title("Fraction of LLM tokens eliminated")
ax[1].set_ylim(0, 100)
ax[1].legend(fontsize=8)
ax[1].grid(alpha=0.3)

xs, w = np.arange(4), 0.38
ax[2].bar(xs - w / 2, [r["rel_rec"] for r in rows], w, label="relational queries")
ax[2].bar(xs + w / 2, [r["tmp_rec"] for r in rows], w, label="temporal queries")
ax[2].set_xticks(xs)
ax[2].set_xticklabels(["graph\nonly", "temporal\nonly", "fixed\nlam=0.5",
                       "adaptive\nlam(q)"], fontsize=8)
ax[2].set_ylabel("Recall@5")
ax[2].set_title("Two-view ablation")
ax[2].set_ylim(0, 1.05)
ax[2].legend(fontsize=8)
ax[2].grid(alpha=0.3, axis="y")

plt.tight_layout()
plt.show()

queries: 23 relational, 40 temporal, 480 traces, 60 sessions

retrieval view                R@5 rel  R@5 tmp  R@5 all     MRR  mean lam
-------------------------------------------------------------------------
entity-graph only (lam=1)       0.739    0.333    0.481   0.455     1.000
temporal only (lam=0)           0.130    1.000    0.683   0.694     0.000
fixed blend (lam=0.5)           0.587    0.988    0.841   0.773     0.500
two-view adaptive lam(q)        0.783    1.000    0.921   0.861     0.397

deterministic calibration over the top-8 retrieved traces per query
  candidate traces examined:        504
  queries with a conflicting key:   37 of 63
  traces discarded as conflicting:  99 (19.6%)
  claim accuracy, top trace only:   0.524
  claim accuracy, after filtering:  0.714

token cost model  (c_write=900, c_read=700, c_answer=1500 tokens)
     N   gen (Q=200)  zero (Q=200)   saving   gen (Q=N/2)  zero (Q=N/2)   saving
    50       485,000       300,000    38.1%       100,000        37,500    62.5%
   200       620,000       300,000    51.6%       400,000       150,000    62.5%
  1000     1,340,000       300,000    77.6%     2,000,000       750,000    62.5%
  2000     2,240,000       300,000    86.6%     4,000,000     1,500,000    62.5%
asymptotic saving at Q = N/2: 62.5%
saving floor as Q/N grows without bound: 31.8%
encoder crossover: LLM-token-equivalents avoided per interaction = 1250, extra index encoding = 8.0; break-even needs kappa > 3.12

Figure 228.1: Zero-token memory operations. Left: cumulative language model tokens spent on memory under a generative write and read path versus a zero-token path, for a fixed query workload and for a workload proportional to the history. Center: the fraction of language model tokens eliminated, approaching one for a fixed workload and settling at a constant for a proportional workload. Right: two-view ablation, showing that the entity-context graph carries relational questions, the temporal hierarchy carries locality questions, and only the query-dependent weighting is competitive on both.

The ablation reproduces the structure of the paper’s own result. The entity-context graph alone reaches Recall@5 of 0.739 on relational questions but only 0.333 on locality questions, while the temporal hierarchy alone inverts that profile, reaching 1.000 on locality questions and collapsing to 0.130 on relational ones. Neither view is adequate on its own, with overall Recall@5 of 0.481 and 0.683 respectively. A fixed blend at \(\lambda = 0.5\) improves on both, reaching 0.841 overall, which shows that the views are genuinely complementary rather than redundant. The query-dependent weight then adds a further gain that a fixed blend cannot reach, 0.921 overall Recall@5 and 0.861 MRR, because it recovers the full 1.000 on locality questions while also lifting relational recall to 0.783. The mean weight it selects across the mixed workload is 0.397, close to the 23 to 40 split between relational and locality questions in the query set. That last row is the ablation that matters: coordinating the two views per query beats using both views uniformly, and the coordination itself costs one index lookup.

Calibration contributes independently of retrieval. Across 504 candidate traces, 37 of the 63 queries retrieved at least one key with contradictory values, and the filter discarded 99 traces, 19.6 percent of the candidates. Reading only the single top-ranked trace would have answered correctly on 0.524 of the queries; aggregating score-weighted support across the retrieved set and discarding the losing value raises that to 0.714. The filter is a dozen lines of dictionary arithmetic and it is the mechanism that makes trace preservation safe: contradictions are permitted to exist in storage precisely because they are resolved at read time, with the resolution visible and auditable rather than baked into a summary written months earlier.

The cost model panel makes the accounting concrete. With \(c_w = 900\), \(c_r = 700\), and \(c_a = 1500\) tokens, a fixed workload of 200 queries against a growing history costs a generative memory system 1,340,000 tokens at \(N = 1000\) and 2,240,000 at \(N = 2000\), against a flat 300,000 for the zero-token path, savings of 77.6 percent and 86.6 percent. When queries scale with the history at \(Q = N/2\) the saving is a constant 62.5 percent at every \(N\), and as the workload becomes arbitrarily query-heavy it never falls below the floor of 31.8 percent derived above. On the encoder side, the accounting avoids 1250 language model token equivalents per interaction while adding 8.0 token equivalents of index encoding, so the break-even would require an encoder token to cost more than 3.12 times a language model token. That is the sense in which the encoder is accounted separately rather than ignored: it is a real cost, it is simply two orders of magnitude smaller than what it displaces.

The reported empirical result is consistent with this picture. Across long-memory and long-context question answering benchmarks, Zero-Mem is competitive with generative memory systems while eliminating language model calls and language model token consumption from memory operations entirely, and with the same final-QA reader and the same context budget it reduces memory-operation time cost by 57.6 percent relative to the fastest compared baseline (Xiao et al. 2026). Two qualifications belong with that number. It measures memory-operation time, not end-to-end latency, so the reader call that both systems share is excluded, and it is measured against the fastest baseline in the comparison rather than against an average, which makes it a conservative rather than a flattering comparison.

For practitioners the lesson generalizes past agent memory. The graph construction pipeline earlier in this chapter uses a language model because extraction over open-domain prose is genuinely hard, but the amount of that pipeline which truly requires generation is smaller than it appears. Entity tagging against a known vocabulary, co-mention graph assembly, personalized PageRank traversal, session and turn indexing, view weighting, and consistency filtering are all deterministic operations over structures the system already has. Zero-Mem is the demonstration that when the domain supplies a usable entity vocabulary, and it usually does in an agent setting where the entities are the user’s projects, contacts, files, and tools, those pieces suffice to serve structured memory at competitive quality with no generation in the loop at all. The right design question is not whether to use a language model for retrieval but which retrieval steps actually need one, and the honest answer in many systems is the reader and nothing else.

228.10 Summary

Graph-based retrieval-augmented generation extends the capabilities of language models by organizing knowledge into explicit relational structures. The graph representation enables multi-hop reasoning, relationship-aware retrieval, and structured context assembly that flat vector retrieval cannot achieve.

The mathematical foundations rest on graph theory, spectral methods, and graph neural networks. Knowledge graph construction requires entity extraction, relation identification, coreference resolution, and entity linking, each presenting distinct technical challenges. Retrieval over graphs combines embedding-based similarity search with graph traversal algorithms, balancing coverage and relevance through techniques such as beam search and personalized PageRank.

Production deployment demands attention to indexing pipelines, caching strategies, service architecture, and comprehensive observability. Evaluation must assess both retrieval quality through metrics such as precision, recall, and NDCG, and generation quality through measures of relevance, consistency, and completeness.

The field continues to evolve with active research in temporal knowledge graphs, hybrid retrieval methods, and more sophisticated graph neural architectures. For practitioners, the key is selecting the appropriate level of complexity for the application domain: simple entity extraction and two-hop traversal suffices for many use cases, while others demand the full machinery of multi-hop reasoning, query decomposition, and temporal awareness.

Edge, Darren, Ha Trinh, Newman Cheng, Joshua Bradley, Alex Chao, Apurva Mody, Steven Truitt, Dasha Metropolitansky, Robert Osazuwa Ness, and Jonathan Larson. 2024. “From Local to Global: A Graph RAG Approach to Query-Focused Summarization.” arXiv Preprint arXiv:2404.16130. https://doi.org/10.48550/arXiv.2404.16130.

Komarov, Mikhail, Ivan Bondarenko, Stanislav Shtuka, Oleg Sedukhin, Roman Shuvalov, Yana Dementyeva, Matvey Solovyov, and Nikolay O. Nikitin. 2026. “RAGU: A Multi-Step GraphRAG Engine with a Compact Domain-Adapted LLM.” arXiv Preprint arXiv:2607.11683.

Microsoft Research. 2024. “LazyGraphRAG: Setting a New Standard for Quality and Cost.” Microsoft Research Blog. https://www.microsoft.com/en-us/research/blog/lazygraphrag-setting-a-new-standard-for-quality-and-cost/.

Xiao, Yilin, Zhehan Zhu, Yujing Zhang, Jin Chen, Zijin Hong, Luyao Zhuang, Qinggang Zhang, et al. 2026. “Zero-Mem: Zero-Token Memory Operations for LLM Agents.” arXiv Preprint arXiv:2607.29377.
